ISETTA

USE AND MAINTENANCE MANUAL

428000372237

4. INSTALLATION

This manual provides information on how to correctly unpack the equipment, the

procedures to

position it and describes how to connect the equipment to the electric network.

4.1 Storage and unpacking

The equipment, with or without the packaging, should be carefully stored inside warehouses or

in areas away from the elements and direct sunlight, at a temperature between 0 and +40 °C.

The equipment should only be moved by qualiﬁ ed personnel operating forklift trucks, the

power of which should be suited to handling the weight of the product: during this operation

the equipment MUST be placed on the special pallet supplied.

Unpack the equipment by removing the screws ﬁ xing it to the pallet.

All packaging materials are recyclable and should be disposed of in accordance with local

regulations. Please destroy "plastic" bags to prevent them from becoming hazardous to

children (suffocation).

4.2 Installation, positioning and ambient conditions

Attention

There should be a good air ﬂ ow around the compressor and condensing unit. Therefore the area

around the unit should not be obstructed by boxes or other objects.

Position the equipment far from sources of heat (radiators, stoves of any kind, etc.) and far from the

in-ﬂ ux of continuous air (caused for instance by fans, air-conditioned inlets, etc.).

Avoid also exposing the equipment to direct sun rays. All of these factors cause the temperature inside

the refrigerated compartment to rise with harmful consequences for the equipment's functionality and

costly consumption of energy. Do not use the equipment outdoors and do not leave it exposed to rain.

4.3 Electrical connection

Attention

Check that the voltage indicated on the appliance is the same as the value on the appliance

identiﬁ cation label and in the table provided in paragraph 2 of this manual, and check that the

required voltage is suitable.

Check on the socket that the power supply voltage provides rated voltage (±10%) when you start up

the compressor.

The plug should be directly connected to the electrical socket. It is forbidden to connect the plug to

the socket by means of multiple socket extensions or adaptors.

The socket of the plant must have a device to disconnect it from the power network (sized to ﬁ t

the load and compliant with the current legislation) which guarantees complete power cut-off in

conditions of overvoltage III (3) and which must therefore protect the circuits against grounding

failures, overloads, and short-circuits.

Do not route the electricity cable in passageways.

Attention

Earthing is necessary and mandatory by law.
