5. TECHNICAL SPECIFICATIONS
This refrigerated cabinet is exclusively intended to display and sell of gelato.
The manufacturer is not liable for injury to persons or damage to property or the equipment
itself caused by the displaying of products other than those described above.
Improper use:
- Food preservation.
- Displaying and/or preserving non-food products (chemicals, pharmaceuticals, etc.).
DISPLAY CONTAINERS ARRANGEMENT
