CW/CWH 511

Using the buttons

Button Short press

Pressed for 2” Pressed for 5” Long press, release, press again

Display of temperatures in

Boiler (L3) and tank (L1)

On/OF Setup Menu (1)

Scroll through Setup

options (2)

Set Pump-out Start Pump-out

Set Regeneration

(mod. with softener only)

Start Regeneration

Set Short Programme

Start Short Programme

Set Medium Programme

Start Medium Programme

Set Long Programme

Start Long Programme

Set P0

Empty tank Start P0 Start Test (1)

Peristaltic pumps in Manual

mode to prime pipes

Reset to DEFAULT

parameters (3)

Technician user only

1) Starting from appliance in “OF” status

2) From setup menu only.

3) Restores the default parameters, for new settings see point (6.3)

A series of operations can be carried out when the dishwasher is first installed to customise it to the user's requirements.

6.1 Contents of display

The two digits provide the following information:

•

Appliance off but powered up: all decimal points on both digits

•

Appliance on and ready for use : Tank temperature

•

Washing phase (programme running, washing pump in operation): Tank temperature

•

Rinsing phase (programme running, washing pump stopped): Boiler temperature

•

Programming phase: See parameter programming section

•

Error message: See error messages section

6.2 Note on display of temperatures

Temperatures shown on the display might not indicate the actual temperature in the tank and/or boiler during heating -

wait about 1’ after the heating elements switch off to see the real temperature.

6.3 Parameter programming procedure

To modify the parameters, proceed as follows starting with the appliance in “OF” status

1) switch the appliance using the On/OF button

2) hold down the button for about 4/5 seconds, until Led L6 goes out and then lights up again, then release the button

and press it again.

3) Press the pump-out button to scroll through the parameters for modification

4) Modify the parameter by pressing button P1

5) During setup operations, Led L1 indicates that the display is showing the description of the parameter, while Led L3

indicates that its value is being displayed (the two alternate)

6) Select the other parameters for modification in the same way and proceed as described above

7) After setting all the appliance parameters, press the button to quit the setup function.
