Smeg CW511MDA-2 [20/24] Cw cwh 511 cw cwh 511

CW/CWH 511

Plates

The basket is able to take 12 soup plates or 18 dinner plates.

Remove solid residues (bones, fruit peel, stones, etc.) and first soak

plates with dried residues of cheese, egg, etc. in water.

TOTAL PUMP-OUT AT THE END OF THE DAY

Press the pump-out button for about 5”, the Led flashes and the

pump-out and automatic tank cleaning phase starts. The word

“UnLoad” scrolls across the display. If the Led does not flash, the

program has not been started and the boiler heating element is not on.

When pump-out is complete the appliance switches off (only 2 dots lit

on the display)

After a total pump-out the filters should be cleaned as described in the relevant point.

Never switch the dishwasher off with water in the tank; always pump out first. Models with softener: if the

set number of cycles (see point 6.8 of the “technical manual”) is reached, regeneration is carried out as well

as the pump-out; the entire process lasts about 15’, after which the appliance switches off automatically.

Resin regeneration (for models with water softener)

Once the set number of wash cycles (see point 6.8 of the “technical manual” is reached), the Led above the button flashes.

Therefore, during the working day resin regeneration must be carried out, following the procedure described below. There are

2 regeneration modes.

1) ON REQUEST

Press the button for 5” to start regenerating; the Led flashes and the

regeneration phase starts. It lasts about 10 minutes, during which time

the Led keeps flashing. (Regeneration cannot be interrupted).

2) AT THE END OF THE DAY

Start the total pump-out and the appliance will perform regeneration

before emptying.

When pump-out is complete the appliance switches off (only 2 dots lit

on the display)
