Animo WKI 20N 3KW SEA [7/14] Installation

12

06/2008WKI n

Type : WKI 40n WKI 60n WKI 80n

Article number : 30125 30130 30135

Buffer stock hot water : 40 ltr. / 320 cups 60 ltr. / 480 cups 80 ltr. / 640 cups

Hour capacity hot water : 90 ltr. / 720 cups 90 ltr. / 720 cups 180 ltr. / 1440 cups

Heating time 20 - 97° : 23 min. 35 min. 25 min.

Tapping speed : 6-9 sec/ltr. 6-9 sec/ltr. 6-9 sec/ltr.

Electrical connection : 3N~380-415V/50-60Cy 3N~380-415V/50-60Cy 3N~380-415V/50-60Cy

Cord length : 1.5 m 1.5 m 1.5 m

Dimensions : see fig. 2 see fig. 2 see fig. 2

Weight empty : 17 kg 19,5 kg 24 kg

filled : 61 kg 82,5 kg 107 kg

Technical alterations are reserved

3. INSTALLATION

This appliance may only be positioned and connected

by a qualified sevice engineer.

• The preparation to install must be done by a

specially trained technician. Always observe

local rules while installing the unit and use

approved materials and parts.

• The technician may only make the

connection of the machine to the wall.

3.2 Electrical connection

Depending on the model, the WKI should be

connected to single phase or rotatory current.

* Always remove the plug from the socket if the machine has to be opened for repair or maintenance.

* Always observe local rules while installing the unit and use approved materials and parts.

* Do not put the machine in areas where the temperature drops below freezing point because there is always

water left in the system.

* Always plug the machine into an earthed wall socket.

* Do not submerge or spray the machine.

* Have all repairs carried out by a specially trained technician.

* When the appliance is in use, some of the components will get very hot.

* If the machine is not used it is advisable to remove the plug from the socket and to turn off the water tap.
