Mitsubishi Electric MFZ-KA50VA [7/30] Air flow velocity and direction adjustment
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

Mitsubishi Electric MFZ-KA50VA [7/30] Air flow velocity and direction adjustment

Mitsubishi Electric MFZ-KA50VA [7/30] Air flow velocity and direction adjustment
7
To select the COOL, DRY or HEAT mode:
1 Press the
ON/OFF
button.
2 Select the operation mode by pressing the
MODE
button.
Each time this button is pressed, the operation mode is changed in sequence:
(AUTO) → (COOL) → (DRY) → (HEAT)
To stop operation:
■
Press the
ON/OFF
button.
After the operation mode is set once, the operation starts in the same mode as
the one set previously from the next time by simply pressing the
ON/OFF
button.
MANUAL OPERATION (COOL, DRY, HEAT)
■
When the set temperature is to be changed:
• Press the
TOO
WARM
button to lower the temperature. One press lowers the temperature by about 1°C.
• Press the
TOO
COOL
button to raise the temperature. One press raises the temperature by about 1°C.
In COOL operation
• When the outside temperature is low, the fan of the outdoor unit turns on and off frequently or decreases the rotation
speed to maintain sufficient cooling capacity.
In DRY operation
• The temperature control (temperature setting) cannot be done.
• The room temperature is slightly lowered in this operation mode.
■
The details of the display on the indoor unit are explained on page 6.
If the air conditioner doesn’t cool or heat effectively…
If the fan speed is set to Low or AUTO, sometimes the air conditioner may not cool or heat the air effectively. In this case,
change the fan speed to Med. or upper.
AIR FLOW VELOCITY AND DIRECTION ADJUSTMENT
AIR FLOW velocity and direction can be selected as required.
1
2
3
4
5
■
To change the AIR FLOW velocity, press the
FAN
button.
Each time the button is pressed, the fan speed is changed in sequence:
(Low) → (Med.) → (High) → (Super High) → (AUTO)
• Use the
(Super High) notch to cool/heat the room more efficiently.
• If the operating sound of the air conditioner disturbs your sleep, use the
(Low) notch.
■
To change the AIR FLOW blowing direction vertically, press the
button.
Each time the button is pressed, the angle of the horizontal vane is changed in
sequence:
(1) → (2) → (3) → (4) → (5) → (SWING) → (AUTO)
SWING OPERATION
Use the swing operation to deliver air evenly.
Recommended horizontal vane range for
more efficient air-conditioning
Use the
(AUTO) position usually.
Use position
(1) or (2) in the COOL or DRY
mode and use positions
(3) to (5) in the
HEAT mode when adjusting to your require-
ments.
HEAT
COOL
DRY
Change the fan speed.
Fan speed: Low or AUTO Fan speed: Med. or upper
HM05B040_MFZ-KA_en.p65 05.4.6, 7:12 PM7
