Installation and Operation of Product Holding Cabinets
24
PARTS LISTS AND ILLUSTRATIONS (CONTINUED)
Locator
P/N Description
FWM3
1X3
FWM3
1X4
FWM3
2X1
FWM3
2X2
FWM3
2X3
FWM3
2X4
FWM3
4X1
FWM3
4X2
FWM3
5X1
1 157828 KEYPAD 1 or 2 2 or 4 3 or 6 4 or 8 2 Or 4 4 or 8 3 or 6
156292 KEYPAD – DOWN ARROWS ONLY 3 2
160585 KEYPAD – DOWN ONLY REAR 3 2
2* See
Note
ELEMENT FOIL HEAT
3 4 2 4 6 8 4 8 5
3 155750 RTD 1K OHM THIN 1 1 1 or 2 2 2 2 4 4 2
4 157829 CONTROL, MAIN FWM 1 1 1 1 1 1 1 1 1
157995 CNOTROL DAYPART - NLP 1 1 1 1 1 1 1
5 155749 TRANSFORMER, 208/240 VAC
1 1 1 1 1 1 1 1 1
156838 TRANSFORMER, 230 VAC
156316 TRANSFORMER, 120 VAC
160840
TRANSFORMER 10 VAC/230 VAC
(AUS/NZ)
6 157743 TERMINAL BLOCK 1 1 1 1 1 1 1 1 1
7 157830 RELAY, SMART POWER MODULE 1 1 1 1 1 1 2 2 1
8
600261
SWITCH, LIGHTED, DPST, 250V
16A, 250V
1 1 1 1 1 1 1 1 1
600228
SWITCH, LIGHTED, DPST, 125V
20A, 120V
9 156288 SCREW, SHOULDER 4 4 4 4 8 8 8 8 10
10 156285 LATCH, PAN 4 4 4 4 8 8 8 8 10
11 155680 NUT #8-32 KEPS 2 2 4 4 4 4 8 8 4
12 155753 THERMOSTAT AUXILIARY 1 1 2 2 2 2 4 4 2
13
155876
LID,FOODWARMER SOLID
(BROILED)(BLACK)
AR AR AR AR AR AR AR AR AR
14
155873
LID,FOODWARMER VENTED
(FRIED)(GRAY)
AR AR AR AR AR AR AR AR AR
15 0653638 SCREW, 1/4-20 X 3/4 4 4 8 8 8 8 16 16 20
16
157506
FACE PLATE w/GASKET, FWM3-
13
2
156354
FACE PLATE w/GASKET, FWM3-
14
2
157859
FACE PLATE w/GASKET, FRONT,
FWM3-21
1
157860
FACE PLATE w/GASKET, REAR,
FWM3-21
1
156485
FACE PLATE w/GASKET, FWM3-
22
2
156558
FACE PLATE w/GASKET, FWM3-
23
2
157960
FACE PLATE w/GASKET, FWM3-
24
2
160469
FACE PLATE w/GASKET, FRONT
FWM3-41
2
160470
FACE PLATE w/GASKET,
REAR FWM3-41
2
156548
FACE PLATE w/GASKET, FWM3-
42
2
156166
FACE PLATE w/GASKET, REAR,
FWM3-51
1
156165
FACE PLATE w/GASKET, FRONT,
FWM3-51
1
Содержание
- Installation and 1
- Operation manual 1
- Product holding cabinet 1
- Table of contents 3
- Electrical warnings 4
- Installation and operation of product holding cabinets 4
- Caution 5
- Installation and operation of product holding cabinets 5
- Installation and operation of product holding cabinets 6
- Manufacturer s introduction 6
- Ac voltage 7
- Frequency 7
- Installation and operation of product holding cabinets 7
- Model fwm3 13 7
- Model shipping weight 7
- Specifications 7
- Ac voltage 8
- Frequency 8
- Installation and operation of product holding cabinets 8
- Model fwm3 14 8
- Model shipping weight 8
- Ac voltage 9
- Frequency 9
- Installation and operation of product holding cabinets 9
- Model fwm3 21 9
- Model shipping weight 9
- Ac voltage 10
- Frequency 10
- Installation and operation of product holding cabinets 10
- Model fwm3 22 10
- Model shipping weight 10
- Ac voltage 11
- Frequency 11
- Installation and operation of product holding cabinets 11
- Model fwm3 23 11
- Model shipping weight 11
- Ac voltage 12
- Frequency 12
- Installation and operation of product holding cabinets 12
- Model fwm3 24 12
- Model shipping weight 12
- Ac voltage 13
- Frequency 13
- Installation and operation of product holding cabinets 13
- Model fwm3 41 13
- Model shipping weight 13
- Ac voltage 14
- Frequency 14
- Installation and operation of product holding cabinets 14
- Model fwm3 42 14
- Model shipping weight 14
- Ac voltage 15
- End front 15
- Frequency 15
- Installation and operation of product holding cabinets 15
- Model fwm3 51 15
- Model shipping weight 15
- Bottom 0 16
- Clearance 16
- Clearance requirements 16
- Earthing instructions 16
- In inches 16
- Installation and operation of product holding cabinets 16
- Installation codes and standards 16
- Installation instructions 16
- Left side 0 16
- Rear open 16
- Requirement 16
- Right side 0 16
- Unit placement 16
- Unpacking unit 16
- External equipotential bonding terminal export only 17
- Figure 1 removal of base pan 17
- Figure 2 placement of bottom unit 17
- Figure 3 fwm3 24 in stacked arrangement 17
- Installation and operation of product holding cabinets 17
- Stacking units 17
- Adjustments adjustments 18
- Cleaning 18
- Cleaning instructions 18
- Closing checklist 18
- Installation and operation of product holding cabinets 18
- Opening checklist 18
- Operation 18
- Operation instructions and 18
- Stainless steel care 18
- Heat tint 19
- Installation and operation of product holding cabinets 19
- Keypad programming 19
- Power up 19
- Preserving restoring 19
- Installation and operation of product holding cabinets 20
- Time decrement 20
- Timer operation 20
- Change meal set 21
- Display link hold time temperature 21
- Enter menu mode 21
- Exit menu mode 21
- Installation and operation of product holding cabinets 21
- Menu mode 21
- Electronic control fault indications 22
- Installation and operation of product holding cabinets 22
- Service hot line 22
- Temperature check procedure 22
- Troubleshooting 22
- Installation and operation of product holding cabinets 23
- Parts lists and illustrations 23
- Installation and operation of product holding cabinets 24
- Parts lists and illustrations continued 24
- Before replacement 25
- Caution 25
- Id number verify heater element 25
- Installation and operation of product holding cabinets 25
- Not shown ce only 25
- Parts lists and illustrations continued 25
- See service label below 25
- Ce only 26
- Fwm 1 high internal wiring schematic 26
- Installation and operation of product holding cabinets 26
- Wiring schematics 26
- Ce only locations all units 27
- Fwm 2 high internal wiring schematic 27
- Heater rtd keypad 27
- Hmc 34 controller 27
- Installation and operation of product holding cabinets 27
- Sps 204 keypad 27
- Usb host 27
- Fwm 4x1 internal wiring schematic 28
- Hmc 34 controller 28
- Installation and operation of product holding cabinets 28
- Sps 204 keypad 28
- Units with rear displays 28
- Usb host 28
- Ce only 29
- F1 f2 f3 f4 29
- Fwm 4x2 internal wiring schematic 29
- Hmc 34 controller 29
- Installation and operation of product holding cabinets 29
- Sps 204 keypad 29
- Usb host 29
- Ce only 30
- F1 f2 f3 30
- Fwm 5x1internal wiring schematic 30
- Hmc 34 controller 30
- Installation and operation of product holding cabinets 30
- R1 r2 r3 30
- Sps 204 keypad 30
- Usb host 30
- Canada latin america 33
- Countries 33
- Customer assistance 33
- Duke asia pacific 33
- Duke corporate 33
- Duke emea europe middle 33
- Duke emea uk ireland nordic 33
- East africa russia 33
- Duke manufacturing co 34
