–22–
L05 — — 96 SIM Duplicated indoor units with priority (Displayed in indoor unit with priority) I/F
L06 L06 No. of indoor units with priority 96 SIM
Duplicated indoor units with priority (Displayed in unit other than indoor unit
with priority)
I/F
L07 — — 99 SIM Group line in individual indoor unit Indoor unit
L08 L08 — 99 SIM Indoor unit group/Address unset Indoor unit, I/F
L09 — — 46 SIM Indoor unit capacity unset Indoor unit
L10 L10 — 88 SIM Outdoor unit capacity unset I/F
L17 — — 46 SIM Outdoor unit type mismatch error I/F
L20 — — 98 SIM Duplicated central control addresses AI-NET, Indoor unit
L26 L26 Number of heat storage units connected 46 SIM Too many heat storage units connected I/F
L27 L27 Number of heat storage units connected 46 SIM Error in number of heat storage units connected I/F
L28 L28 — 46 SIM Too many outdoor units connected I/F
L29 L29 Number of IPDU (*1) CF SIM No. of IPDU error I/F
L30 L30 Detected indoor unit address b6 SIM Indoor unit outside interlock Indoor unit
— L31 — — — Extended I/C error I/F
P01 — — 11 ALT Indoor fan motor error Indoor unit
P03 P03 — 1E ALT Discharge temp. TD1 error I/F
P04 P04
01:Comp. 1 side
02:Comp. 2 side
03:Comp. 3 side
21 ALT High-pressure SW system operation IPDU
P05 P05
00:
01:Comp. 1 side
02:Comp. 2 side
03:Comp. 3 side
AF ALT
Phase missing detection/Power failure detection
Inverter DC voltage error (comp.)
Inverter DC voltage error (comp.)
Inverter DC voltage error (comp.)
I/F
P07 P07
01:Comp. 1 side
02:Comp. 2 side
03:Comp. 3 side
IC ALT Heat sink overheat error IPDU, I/F
P09 P09 Detected heat storage address 47 ALT No heat storage unit water error Heat storage unit
P10 P10 Detected indoor unit address Ob ALT Indoor unit overflow error Indoor unit
P12 — — 11 ALT Indoor unit fan motor error Indoor unit
P13 P13 — 47 ALT Outdoor liquid back detection error I/F
P15 P15
01:TS condition
02:TD condition
AE ALT Gas leak detection I/F
P17 P17 — bb ALT Discharge temp. TD2 error I/F
P18 P18 — E2 ALT Discharge temp. TD3 error I/F
P19 P19 Detected outdoor unit number O8 ALT 4-way valve inverse error I/F
P20 P20 — 22 ALT High-pressure protective operation I/F
P22 P22
0*:IGBT circuit
1*:Position detective circuit error
3*:Motor lock error
4*:Motor current detection
C*:TH sensor error
D*:TH sensor error
E*:Inverter DC voltage error (outdoor unit
fan)
1A ALT
Outdoor unit fan IPDU error
Note: Ignore 0 to F displayed in “*” position.
IPDU
P26 P26
01:Comp. 1 side
02:Comp. 2 side
03:Comp. 3 side
14 ALT G-TR short protection error IPDU
Check code Wireless remote controller
Check code name Judging device
Wired remote
controller display
Outdoor unit 7-segment display
AI-NET central
control display
Sensor block display of receiving unit
Auxiliary code Operation Timer Ready Flash
43-EN 44-EN
