–24–
13Specifications
* Under 70 dBA
Model
Sound power level (dBA)
Weight (kg) Main unit
Cooling Heating
MMD-AP0076BH-E * * 23
MMD-AP0096BH-E * * 23
MMD-AP0126BH-E * * 23
MMD-AP0156BH-E * * 23
MMD-AP0186BH-E * * 23
MMD-AP0246BH-E * * 30
MMD-AP0276BH-E * * 30
MMD-AP0306BH-E * * 30
MMD-AP0366BH-E * * 40
MMD-AP0486BH-E * * 40
MMD-AP0566BH-E * * 40
Declaration of Conformity
NOTE
This declaration becomes invalid if technical or operational modifications are introduced without the manufacturer’s
consent.
Manufacturer: Toshiba Carrier Corporation
336 Tadehara, Fuji-shi, Shizuoka-ken 416-8521 JAPAN
Authorized
Representative/TCF
holder:
Nick Ball
Toshiba EMEA Engineering Director
Toshiba Carrier UK Ltd.
Porsham Close, Belliver Industrial Estate,
PLYMOUTH, Devon, PL6 7DB.
United Kingdom
Hereby declares that the machinery described below:
Generic Denomination: Air Conditioner
Model/type: MMD-AP0076BH-E, MMD-AP0096BH-E, MMD-AP0126BH-E, MMD-AP0156BH-E,
MMD-AP0186BH-E, MMD-AP0246BH-E, MMD-AP0276BH-E, MMD-AP0306BH-E,
MMD-AP0366BH-E, MMD-AP0486BH-E, MMD-AP0566BH-E
Commercial name: Super Modular Multi System Air Conditioner
Super Heat Recovery Multi System Air Conditioner
Mini-Super Modular Multi System Air Conditioner (MiNi-SMMS series)
Complies with the provisions of the “Machinery” Directive (Directive 2006/42/EC) and the regulations transposing
into national law
“Declaration of incorporation of partly completed machinery”
Must not be put into service until the final machinery into which it is to be incorporated has been declared in
conformity with the provisions of this Directive, where appropriate.
Complies with the provisions of the following harmonized standard:
EN 378-2: 2008+A1: 2009
