Liebherr ICNP 3356 [10/14] Maintenance
![Liebherr ICNP 3356 [10/14] Maintenance](/views2/1333800/page10/bga.png)
u
Using the Up setting button, freezer compartment
Fig. 2 (11)
and Down setting button, freezer compartment
Fig. 2 (12)
select E.
u
To confirm: briefly press the SuperFrost button
Fig. 2 (13)
.
u
To increase the water intake time: press the Up
setting button, freezer compartment
Fig. 2 (11)
.
u
To reduce the water intake time: press the Down
setting button, freezer compartment
Fig. 2 (12)
.
u
To confirm: press the SuperFrost button
Fig. 2 (13)
.
u
To deactivate the setting mode: press the On/Off button,
freezer compartment
Fig. 2 (9)
.
-or-
u
Wait for 5 minutes.
w
The temperature is indicated again in the temperature
display.
Switching off the IceMaker*
If no ice cubes are needed, the IceMaker can be switched off
independently of the freezer compartment.
When the IceMaker is switched off, the IceMaker drawer can
also be used for freezing and storing food.
u
Press the On/Off button for about 1 second until the LED
goes out.
w
The IceMaker symbol
Fig. 2 (19)
goes out.
u
Clean the IceMaker.
w
This ensures that no water or ice remains in the IceMaker.
6 Maintenance
6.1 Defrosting with NoFrost
The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The defrost water evaporates due to the compressor heat.
Drops of water on the rear wall are perfectly normal.
u
Regularly clean the drain opening to allow the water to flow
away (see 6.2) .
Freezer compartment:
The moisture condenses on the evaporator, is periodically
defrosted and evaporates.
u
The appliance does not have to be manually defrosted.
6.2 Cleaning the appliance
WARNING
Risk of injury and damage as a result of hot steam!
Hot steam can lead to burns and can damage the surfaces.
u
Do not use any steam cleaners!
NOTICE
Incorrect cleaning damages the appliance!
u
Do not use cleaning agents in concentrated form.
u
Do not use any scouring or abrasive sponges or steel wool.
u
Do not use any sharp or abrasive cleaning agents, nor any
that contain sand, chloride or acid.
u
Do not use chemical solvents.
u
Do not damage or remove the type plate on the inside of the
appliance. It is important for the customer service.
u
Do not pull off, bend or damage cables or other compo-
nents.
u
Do not allow any cleaning water to enter the drain channel,
ventilation grille or electrical parts.
u
Please use soft cleaning cloths and a universal pH-neutral
cleaning agent.
u
Please use cleaning and care products suitable for contact
with foodstuffs in the appliance interior.
u
Empty appliance.
u
Pull out the power plug.
u
Clean plastic outer and inner surfaces with lukewarm
water and a little washing-up liquid.
u
Clean drain hole: Remove deposits
with a narrow instrument, e.g. a
cotton bud.
u
Most of the parts can be dismantled for cleaning: see the
relevant chapter.
u
Clean drawers by hand with lukewarm water and a little
washing up liquid.
u
All the other fittings can be put in the dishwasher.
u
Only use a damp cloth to clean the telescopic rails. The
grease in the runners is for lubrication purposes and must
not be removed.
u
Empty water collect tray: remove
water tank. Carefully unlatch tray
at front and then remove from
below.*
*
After cleaning:
u
Wipe dry the appliance and items of equipment.
u
Connect the appliance and switch it on again.
u
Switch on SuperFrost (see 5.5.4) .
When the temperature is sufficiently cold:
u
Put the food back inside.
6.3 Cleaning the IceMaker*
The drawer of the IceMaker has to be emptied and slid in.
u
To activate the setting mode: press the SuperFrost button
Fig. 2 (13)
for about 5 s.
w
The display indicates c.
w
The menu symbol
Fig. 2 (17)
shines.
u
Using the Up setting button, freezer compartment
Fig. 2 (11)
/ Down setting button, freezer compartment
Fig. 2 (12)
select I.
u
To confirm: press the SuperFrost button
Fig. 2 (13)
.
u
Using the Up setting button, freezer compartment
Fig. 2 (11)
/ Down setting button, freezer compart-
ment
Fig. 2 (12)
select Ic.
u
To confirm: press the SuperFrost button
Fig. 2 (13)
.
w
The IceMaker moves into the cleaning position and switches
off.
u
To deactivate the setting mode: press the On/Off button,
freezer compartment
Fig. 2 (9)
.
w
The temperature is indicated again in the temperature
display.
u
Remove the drawer.
u
Clean the ice cube tray and drawer with warm water. If
necessary, use mild washing-up liquid. Then rinse.
u
Slide in the drawer again.
u
Leave the IceMaker switched off in this position.
-or-
Maintenance
10 * Depending on model and options
