Liebherr ICNP 3356 [12/14] Decommissioning
![Liebherr ICNP 3356 [12/14] Decommissioning](/views2/1333800/page12/bgc.png)
u
Check the quality of the food. Do not consume spoiled food.
Do not re-freeze thawed food.
DEMO shines in the temperature display.
→
The demo mode is activated.
u
Please contact the after-sales service (see Maintenance).
The outer surfaces of the appliance are warm*.
→
The heat of the refrigeration circuit is used to prevent
condensate from forming.
u
This is normal.
The IceMaker cannot be switched on. *
→
The appliance and therefore the IceMaker are not
connected.
u
Connect the appliance to the mains (see Putting into opera-
tion).
The IceMaker does not make any ice cubes.*
→
The IceMaker is not switched on.
u
Switch on the IceMaker.
→
The drawer of the IceMaker is not properly closed.
u
Close the drawer properly.
→
The water tank is not correctly inserted.
u
Insert the water tank.
→
There is not enough water in the water tank.
u
Fill the water tank.
The LED of the IceMaker flashes.*
→
There is not enough water in the water tank.
u
Fill the water tank.
→
If the LED flashes and the water tank is full, the IceMaker is
defective.
u
Please contact the after-sales service (see Maintenance).
The temperature is not cold enough.
→
The door of the appliance is not properly closed.
u
Close the door of the appliance.
→
Insufficient ventilation.
u
Keep ventilation grille clear, and clean it.
→
The ambient temperature is too high.
u
Solution: (see 1.2) .
→
The appliance was opened too frequently or for too long.
u
Wait to see whether the appliance reaches the required
temperature by itself. If not, please contact the after sales
service (see Maintenance).
→
Too much fresh food was placed inside without SuperFrost.
u
Solution: (see 5.5.4)
→
The temperature is incorrectly set.
u
Set the temperature to a colder setting and check after 24
hours.
→
The appliance is too close to a source of heat (stove, heater
etc).
u
Change the position of the appliance or the source of heat.
→
The appliance was not inserted properly into the recess.
u
Check whether the appliance was inserted correctly and
the door closes properly.
The internal light does not come on.
→
The appliance is not switched on.
u
Switch on the appliance.
→
The door was open longer than 15 min.
u
The interior light automatically switches off if the door has
been open for about 15 min.
→
The LED illumination is defective or the cover is damaged:
WARNING
Risk of injury due to electric shock!
Live parts are located under the cover.
u
Have the LED interior light changed or repaired only by the
customer service or by specialized personnel trained for the
purpose.
WARNING
Danger of injury by LED lamp!
The light intensity of the LED illumination corresponds to laser
class 1/1M.
If the cover is defective:
u
Do not look into the illumination with optical lenses from the
immediate proximity. This can cause injury to the eyes.
The door gasket is defective or should be replaced for
other reasons.*
→
In some units, the seal around the door can be replaced.
You will not need any special tools to do this.
u
Please contact the after-sales service (see Maintenance).
The unit has iced up or condensation has formed.*
→
The door seal may have also slipped out of its groove.
u
Check to ensure that the door seal is seated properly in the
groove.
8 Decommissioning
8.1 Switching off the appliance
Note
u
To switch off the entire appliance it is necessary only to
switch off the freezer compartment.
8.1.1 Switching off the freezer compartment
w
A long beep is emitted. The temperature displays
are dark. The appliance is switched off.
w
If the appliance cannot be switched off, the child
lock function is active (see 5.1) .
8.1.2 Switching off the refrigerator compart-
ment
Note
u
The refrigerator compartment can be switched off sepa-
rately, if required.
u
Press the refrigerator compartment On/Off button
Fig. 2 (1)
for approx. 2 seconds.
w
The temperature display of the refrigerator compartment
Fig. 2 (2)
is dark. The refrigerator compartment is switched
off.
8.2 Taking the appliance out of service*
u
Empty the appliance.
u
Put the IceMaker in the cleaning position (see Mainte-
nance).
u
Switch off the appliance (see Decommissioning).
u
Remove mains connector.
u
Clean the appliance (see 6.2) .
u
Leave the door open to prevent odour.
Decommissioning
12 * Depending on model and options
