Liebherr ICNP 3356 [8/14] Thawing food
![Liebherr ICNP 3356 [8/14] Thawing food](/views2/1333800/page8/bg8.png)
In order that the food is rapidly frozen through to the core, do
not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg
- Meat up to 2.5 kg
u
Pack the food in portions in freezer bags, reusable plastic,
metal or aluminium containers.
5.5.2 Thawing food
- in the refrigerator compartment
- in a microwave oven
- in a conventional or fan oven
- at room temperature
u
Remove only as much food as is required. Use thawed food
as quickly as possible.
u
Food once thawed should be re-frozen only in exceptional
cases.
5.5.3 Setting the temperature
The appliance is pre-set for normal operation.
The temperature can be set from -15 °C to -26 °C, the recom-
mended temperature is -18 °C.
u
To set the temperature higher: press Up button, freezer
compartment
Fig. 2 (11)
.
u
To set the temperature lower: press Down button, freezer
compartment
Fig. 2 (12)
.
w
When the button is pressed the first time, the previous value
is indicated in the temperature display of the freezer
compartment.
u
To change the temperature in 1 °C steps: briefly press the
button.
-or-
u
To change the temperature continuously: hold down the
button.
w
The value is displayed flashing during the setting operation.
w
The actual temperature is displayed approx. 5 seconds after
the button is last pressed. The temperature gradually
adjusts to the new value.
5.5.4 SuperFrost
With this function you can freeze fresh food quickly
through to the core. The appliance operates with
maximum refrigeration. The noise of the refrigeration
unit may be temporarily louder as a result.
The maximum amount of fresh food which can be frozen in 24 h
is indicated on the type plate under “freezing capacity ... kg/
24h”. This amount varies according to the model and climate
rating.
You have to activate SuperFrost in good time, depending on
how much fresh food is to be frozen: about 6 hours before
placing the food inside in case of small amounts and about 24
hours in advance in case of the maximum amount of food to be
frozen.
Wrap produce and spread it out as far as possible. Do not allow
produce to be frozen to touch produce that is already frozen to
prevent the latter thawing.
You do not have to activate SuperFrost in the following cases:
-
when placing frozen food in the freezer
-
when freezing up to approx. 2 kg fresh food daily
Freezing with SuperFrost
u
Briefly press the SuperFrost button
Fig. 2 (13)
once.
w
The SuperFrost symbol
Fig. 2 (14)
shines.
w
The freezing temperature drops, the appliance operates with
the maximum cooling capacity.
For a smaller quantity of produce to be frozen:
u
wait approx. 6 h.
u
Place wrapped produce in the top drawers.
For the maximum quantity of produce to be frozen:
u
wait approx. 24 h.
u
Remove top drawers and place produce directly on the top
shelves.
w
SuperFrost is automatically deactivated. Depending on the
quantity placed inside, after 30 h at the earliest, 65 h at the
latest.
w
The SuperFrost symbol
Fig. 2 (14)
extinguishes once
freezing is completed.
u
Place produce in the drawers and push the latter back in
again.
w
The appliance continues to operate in the energy-saving,
normal mode.
5.5.5 Drawers
Note
The energy consumption increases and the cooling perform-
ance decreases if there is insufficient ventilation.
For appliances with NoFrost:
u
Leave the bottom drawer in the appliance!
u
Always keep the air slits of the fan free at the rear wall!
u
To store frozen food directly on the shelves: pull the drawer
forwards and lift it out.
5.5.6 Shelves
u
To remove the shelf: lift up at
the front and pull out.
u
To put the shelf back: simply
push in as far as it will go.
5.5.7 VarioSpace
Apart from being able to
remove the drawers, you can
also remove the shelves,
creating space for large items
of frozen food. Poultry, meat,
large pieces of game and high
bakery products can be frozen
in one piece and prepared.
u
The maximum load of frozen
food for the drawers is 25 kg
each and for the shelves
35 kg each.
5.5.8 Information system
Fig. 9
(1) Ready meals, ice cream (4) Sausage, bread
(2) Pork, fish (5) Game, mushrooms
(3) Fruit, vegetables (6) Poultry, beef / veal
Control
8 * Depending on model and options
