Liebherr ICNP 3356 [11/14] Customer service
![Liebherr ICNP 3356 [11/14] Customer service](/views2/1333800/page11/bgb.png)
NOTICE
Rinse agent residue in the ice compartment and drawer.
Nausea or irritation of the mucous membrane.
u
Remove rinse agent residue: Discard the first three batches
of ice cubes.
u
Switch the IceMaker on (see 5.5.10) .
6.4 Customer service
First check whether you can correct the fault yourself by refer-
ence to the list (see Malfunction). If this is not the case, please
contact the customer service whose address is given in the
enclosed customer service list.
WARNING
Risk of injury if repair work is not carried out professionally!
u
Have any repairs and action - not expressly specified - on
the appliance and mains cable carried out by service
personnel only. (see Maintenance)
u
Read the appliance
designation
Fig. 12 (1)
, service
No.
Fig. 12 (2)
and
serial No.
Fig. 12 (3)
off the type plate
located inside the
appliance on the left-
hand side.
Fig. 12
u
Notify the customer service, specifying the fault, appliance
designation
Fig. 12 (1)
, service No.
Fig. 12 (2)
and serial No.
Fig. 12 (3)
.
w
This will help us to provide you with a faster and more accu-
rate service.
u
Keep the appliance closed until the customer service
arrives.
w
The food will stay cool longer.
u
Pull out the mains plug (not by pulling the connecting cable)
or switch off the fuse.
7 Malfunctions
Your appliance is designed and manufactured for a long life
span and reliable operation. If a malfunction nonetheless
occurs during operation, check whether it is due to a handling
error. In this case you will have to be charged for the costs
incurred, even during the warranty period. You may be able to
rectify the following faults yourself:
Appliance does not work.
→
The appliance is not switched on.
u
Switch on the appliance.
→
The power plug is not properly inserted in the wall socket.
u
Check power plug.
→
The fuse of the wall socket is not in order.
u
Check fuse.
The compressor runs for a long time.
→
The compressor switches to a low speed when little cold is
needed. Although the running time is increased as a result,
energy is saved.
u
This is normal in energy-saving models.
→
SuperFrost is activated.
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
→
SuperCool is activated.
u
The compressor runs for longer in order to rapidly cool the
food. This is normal.
A LED on the bottom rear of the appliance (at the
compressor) flashes repeatedly every 5 seconds*.
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
Excessive noise.
→
Due to the various speed steps, speed-regulated* compres-
sors can generate different running noises.
u
The sound is normal.
A bubbling and gurgling noise.
→
This noise comes from the refrigerant flowing in the refriger-
ation circuit.
u
The sound is normal.
A quiet clicking noise.
→
The noise is produced whenever the refrigeration unit
(motor) automatically switches on or off.
u
The sound is normal.
A hum. It is briefly a little louder when the refrigeration
unit (the motor) switches on.
→
The refrigeration increases automatically when the
SuperFrost, function is activated, fresh food has just been
placed in the appliance or the door has been left open for a
while.
u
The sound is normal.
→
The refrigeration increases automatically when the
SuperCool function is activated, fresh food has just been
placed in the appliance or the door has been left open for a
while.
u
The sound is normal.
→
The ambient temperature is too high.
u
Solution: (see 1.2)
A low hum.
→
The sound is produced by air flow noise of the fan.
u
The sound is normal.
Vibratory noise.
→
The appliance is not fixed to the ground. The running of the
cooling unit therefore makes objects and adjacent furniture
vibrate.
u
Check installation and reposition appliance as required.
u
Move bottles and containers apart.
Flow sound at the soft stop mechanism.
→
The noise is produced when the door is opened and
closed.
u
The sound is normal.
Hum of the water tank pump.*
→
When water is pumped out of the water reservoir, a brief
hum of the pump can be heard.
u
The sound is normal.
The temperature display indicates: F0 to F9
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
The temperature display reads:FE*
→
There is a fault.
u
Please contact the after-sales service (see Maintenance).
Power failure flashes in the temperature display . The
highest temperature reached during power failure is indi-
cated in the temperature display.
→
The freezer temperature rose too high over the last hours or
days due to a power failure or power interruption. When the
power interruption is over, the appliance will continue to
operate in the last temperature setting.
u
To cancel the display of the warmest temperature: press
alarm button
Fig. 2 (15)
.
Malfunctions
* Depending on model and options 11
