TECHNICAL DESCRIPTION

The chimney stoves of La Nordica are suitable to heat living spaces for some periods. As fuel, wood logs are used. The appliance

works as an intermittent operating appliance.

The stove is made of raw and enamelled meltings of cast iron.

The hearth is totally sheathed with single cast-iron sheets. Its back is extractable. Thanks to calibrated holes, made on the same

back, it is guaranteed a supply of pre-heated air inside the hearth, thus obtaining a post-combustion which increases the efciency

and reduces the emission of the unburnt gases. Inside it there is a turning and extractable grate. The inside smoke plate, reects the

re radiation and increases the internal temperature of the combustion chamber. This process together with the exhaust gases ows,

ACCESSORIES

POKER GLOVE

SERIES SERIES

The stove is equipped with controls of primary and secondary air by which it is adjusted the combustion air.

1A - PRIMARY air register (Picture 6 )

With the air register located under the door of the hearth, it is possible to adjust the air ow through the ash drawer and the grating

in direction of the fuel. The primary air is necessary for the combustion process during the ignition. In order to open the passage

of primary air the lever should be completely pulled. The ash drawer has to be emptied regularly, so that ash cannot hinder the

intake of primary air for the combustion. Primary air is also necessary to keep re live. When the control is completely on the left,

the register is closed, when the knob is completely on the right the register is opened. During the combustion of wood, the primary

Hourly wood consumption in kg / h PRIMARY air SECONDARY air TERTIARY AIR

CANDY

2 Picture 6 pos. 1 Picture 6 pos. 3 PRE-ADJUSTED

BRIGITTA

1,7 1/4 OPEN OPEN PRE-ADJUSTED

FLUE

Essential requirements for correct appliance operation:

The following materials are FORBIDDEN and compromise the good operation of the appliance: asbestos cement, galvanised steel,

rough and porous internal surfaces. Picture 1 shows some example solutions.

The minimum section must be 4 dm

(for example 20x20 cm) for appliances whose pipe dimensions are less than 200 mm,

or 6.25 dm

The draught created by your ue must be sufcient but not excessive.

A section of the ue which is too large can present a volume which is too large to heat and therefore cause operating difculties

for the appliance; to avoid this, it is necessary to intubate the appliance for its entire height. A section which is too small causes a

reduction in draught.
