ACCESSORIES
POKER GLOVE Chrome plated oven GRILLE
ITALY Built IN SERIES SERIES OPTIONAL
The cooker is equipped with controls of primary and secondary air by which it is adjusted the combustion air.
1A – PRIMARY AIR CONTROL (Picture 6 at page 62)
With the inferior air control, which is on the re door, it is adjusted the passage of primary air into the low part of the cooker, through
the drawer of ash and the grate in the fuel direction. The primary air is necessary for the combustion process. The ash drawer must be
regularly emptied, so that the ash does not obstruct the primary air entry for the combustion. Through the primary air the re is also kept
alive. When the knob is completely on the left, the register is closed, when the knob is completely on the right the register is opened.
During wood combustion, the register of primary air must be opened only for a while, because otherwise the wood burns too fast and the
cooker may overheat.
2A – SECONDARY AIR CONTROL (Picture 6 at page 62)
On the hearth door there is the secondary air register. This knob must be totally moved to the right in order to open the control, especially
for wood combustion (see paragraph Table). The secondary air, passing between the double glass of the re door, heats itself starting the
double combustion and keeping at the same time the glass clean (with open register).
B – SMOKES control (Picture 6 at page 62)
(Conversion of the cooker function to the cooker, bake oven and heating function).
The smokes control, in the style of a chromed pull push lever, can be found on the top right corner of the front side of the cooker, between
the protection bar and the oven door. This control has two settings:
HOB COOKING: when the bar is pushed to the back of the cooker, the combustion gases ow around the oven and directly into the ue
and up to the chimney. OVEN COOKING: when the control bar is pulled out, the combustion gases ow around the oven, heating it.
The control regulation necessary in order to obtain nominal caloric output is the following (see Cap. TECHNICAL DATA):
PRIMARY air SECONDARY air TERTIARY air
ITALY Built IN CLOSED OPEN PRE-ADJUSTED
To ignite the ame follow the instructions below (see Cap. IGNITION) :
• Bring the ue gas control to the cooker position (any buttery valve placed on the ue gas exhaust pipe must also be opened).
• Open the primary and secondary air control.
• After having started the re with small pieces of wood and waited until it is well lit.
• Bring the ue gas control to the oven position.
• Close any buttery valve placed on the ue gas exhaust pipe must also be opened.
The control regulation during the ignition phase is the following :
PRIMARY air SECONDARY air SMOKES control
ITALY Built IN OPEN OPEN Cooker function
6. FLUE
Essential requirements for correct appliance operation:
• the internal section must preferably be circular;
• the appliance must be thermally insulated and impermeable and built with suitable materials which are resistant to heat, combustion
products and any condensation;
• there must be no narrowing and vertical passages with deviations must not be greater than 45°;
• if already used, it must be clean;
• the technical data from the instruction manual must be respected;
If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.
For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.
A section which is too small causes a reduction in draught. A minimum height of 4 m is advisable.
The following materials are FORBIDDEN and compromise the good operation of the appliance: asbestos cement, galvanised steel, rough
and porous internal surfaces. Picture 1 at page 59 shows some example solutions.
The minimum section must be 4 dm
2
(for example 20x20 cm) for appliances whose pipe dimensions are less than 200 mm, or 6.25
dm
2
(for example 25x25 cm) for appliances with a diameter of more than 200 mm.
The draught created by your ue must be sufcient but not excessive.
A section of the ue which is too large can present a volume which is too large to heat and therefore cause operating difculties for the
appliance; to avoid this, it is necessary to intubate the appliance for its entire height. A section which is too small causes a reduction in
draught.
ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by
UNI 10683 standard. The ue must be at a suitably distance from ammable or combustible material using suitable insulation or
an air space.
It is FORBIDDEN to pass system piping or air ducts inside the ue. It is also forbidden to create moveable or xed openings on the ue
itself, for the connection of further different appliances (See chapter CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE).
