![La Nordica Italy Built-in [19/68] Chimney pot](/views2/1334673/page19/bg13.png)
6.1. CHIMNEY POT
The ue draught depends on the suitability of the chimney pot.
It is therefore essential that, if built in a handcrafted way, the exit section is more than twice the internal section of the ue
(Picture 2 at page 59) .
As it must always go past the ridge of the roof, the chimney pot must ensure exhaust even in the presence of wind (Picture 3 at page 60).
The chimney pot must meet the following requirements:
• Have an internal section equivalent to that of the chimney.
• Have a useful exit section of double the internal section of the ue.
• Be built so as to prevent rain, snow or any foreign body entering the ue.
• Be easy to inspect, for any maintenance and cleaning operations.
ITALY BUILT IN
7095401 19
6.2. CONNECTION TO THE CHIMNEY
Products with automatic door closing (type 1) must operate, for safety reasons, with the furnace door closed (except during the fuel loading
or ash removal phases).
Products with non-automatic door closing (type 2) must be connected to their own ue.
Operation with doors open is only allowed when supervised.
The connection pipe to the ue must be as short as possible, straight horizontal and positioned slightly in ascent, and watertight.
Connection must be carried out with stable and robust pipes,comply with all current Standards and Regulations and to those envisioned
by the law, and be hermetically secured to the ue. The internal diameter of the connection pipe must correspond to the external diameter
of the appliance ue gas exhaust stub pipe (DIN 1298).
ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by
UNI 10683 standard. The ue must be properly spaced from any ammable materials or fuels through a proper insulation or an air cavity.
Minimum distance safety 25 cm.
IMPORTANT: the unused ue gas exhaust hole must be covered with its respective cap (See chapter: DIMENSIONS).
The chimney pressure (DRAUGHT) must be at least 12 Pa Pascal (=1.2 mm of water column). The measurement must always be carried
out when the appliance is hot (nominal caloric power). When the pressure exceeds 17 Pascal, it is necessary to reduce it through the
installation of an additional draught regulator (false air valve) on the exhaust pipe or in the chimney, according to the regulations in force.
For correct appliance operation, it is essential that sufcient air for combustion is introduced into the place of installation (see paragraph
AIR FLOW IN THE PLACE OF INSTALLATION DURING COMBUSTION).
6.3. CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE
The ue gas channel is the stretch of piping which connects the product to the ue. In the connection, these simple but extremely important
principles must be respected:
• under no circumstances use a ue gas channel with a diameter less than that of the exhaust clamp with which the product is equipped;
• each metre of the horizontal stretch of the ue gas channel causes a slight loss of head which must be compensated if necessary by
elevating the ue;
• the horizontal stretch must never exceed 2 metres (UNI 10683);
• each bend of the ue gas channel slightly reduces the ue draught which must be compensated if necessary by elevating it suitably;
• The UNI 10683 – ITALY regulation requires that under no circumstances must there be more than 2 bends or variations in direction
including the intake into the ue.
If the user wishes to use the ue as a replace or open hearth, it is necessary to seal the hood below the entrance point of the ue gas
channel pos. A Picture 5 at page 61.
If the ue is then too big (e.g. 30x40cm or 40x50cm), it is necessary to intubate it with a stainless steel tube with a diameter of at least
200mm, pos. B, taking care to close the remaining spaces between the pipe and the ue immediately under the chimney pot pos. C.
7. AIR FLOW IN THE PLACE OF INSTALLATION DURING COMBUSTION
As the product draw their combustion air from the place of installation, it is MANDATORY that in the place itself, a sufcient quantity of air
is introduced. If windows and doors are airtight (e.g. built according to energy saving criteria), it is possible that the fresh air intake is no
longer guaranteed and this jeopardises the draught of the appliance and your health and safety. It is therefore necessary to guarantee a
supply of fresh air through an external air inlet placed near the appliance or by placing piping for combustion air which leads outside or to
a nearby airy place, with the exception of the boiler room or garage (FORBIDDEN).
The intake of air for combustion in the place of installation must not be obstructed during operation of the product. It is absolutely essential
that in environments in which products are operated with a natural chimney draught, as much air as is necessary for combustion is
introduced, i.e. up to 20 (<11kW) m³/hour. The natural recirculation of air must be guaranteed by some xed openings to the outside. Their
size is established by regulations regarding the subject. Ask for information from a chimneys weep. The openings must be protected with
grills and must never be blocked up. An extractor hood (suction) installed in the same room or in a neighbouring one causes a depression in
the environment. This causes the leakage of burnt gas (dense smoke, smell); it is therefore necessary to ensure a greater ow of fresh air.
The depression of an extractor hood can, in the worst case scenario, transform the ue of the product into an external air inlet,
re sucking the ue gases into the environment with very serious consequences for persons.
