• if already used, it must be clean;

• the technical data from the instruction manual must be respected;

If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.

For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.

A section which is too small causes a reduction in draught. A minimum height of 4 m is advisable.

The following materials are FORBIDDEN and compromise the good operation of the appliance: asbestos cement, galvanised steel, rough

and porous internal surfaces. Picture 1 at page 64 shows some example solutions.

appliance; to avoid this, it is necessary to intubate the appliance for its entire height. A section which is too small causes a reduction in

draught.

ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by

UNI 10683 standard. The ue must be at a suitably distance from ammable or combustible material using suitable insulation or

an air space.

It is FORBIDDEN to pass system piping or air ducts inside the ue. It is also forbidden to create moveable or xed openings on the ue

itself, for the connection of further different appliances (See chapter CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE).

7.1. CHIMNEY POT

The ue draught depends on the suitability of the chimney pot.

It is therefore essential that, if built in a handcrafted way, the exit section is more than twice the internal section of the ue

• Be easy to inspect, for any maintenance and cleaning operations.

7.2. CONNECTION TO THE CHIMNEY

Products with automatic door closing (type 1) must operate, for safety reasons, with the furnace door closed (except during the fuel loading

or ash removal phases).

Products with non-automatic door closing (type 2) must be connected to their own ue.

Operation with doors open is only allowed when supervised.

The connection pipe to the ue must be as short as possible, straight horizontal and positioned slightly in ascent, and watertight.

Connection must be carried out with stable and robust pipes,comply with all current Standards and Regulations and to those envisioned

by the law, and be hermetically secured to the ue. The internal diameter of the connection pipe must correspond to the external diameter

of the appliance ue gas exhaust stub pipe (DIN 1298).

installation of an additional draught regulator (false air valve) on the exhaust pipe or in the chimney, according to the regulations in force.

For correct appliance operation, it is essential that sufcient air for combustion is introduced into the place of installation (see paragraph

AIR FLOW IN THE PLACE OF INSTALLATION DURING COMBUSTION).

7.3. CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE

The ue gas channel is the stretch of piping which connects the product to the ue. In the connection, these simple but extremely important

principles must be respected:

• under no circumstances use a ue gas channel with a diameter less than that of the exhaust clamp with which the product is equipped;

• each metre of the horizontal stretch of the ue gas channel causes a slight loss of head which must be compensated if necessary by

elevating the ue;

• the horizontal stretch must never exceed 2 metres (UNI 10683);

200mm, pos. B, taking care to close the remaining spaces between the pipe and the ue immediately under the chimney pot pos. C.
