La Nordica Rosetta Natural Stone [25/76] Calculation of the thermal power
![La Nordica Rosetta Natural Stone [25/76] Calculation of the thermal power](/views2/1334698/page25/bg19.png)
rOSa - rOSEtta Bii - rOSEtta SiniStra Bii
1095080 25
12.13. MAINTENANCE OF THE OVEN (where existing)
To avoid the possible forming of rust it is recommended:
- To let the steam getting out of the oven to reduce the formation of any condensation by opening the door briey and carefully (1 or 2
times, or more often in case of cooking food very humid and with longer cooking times);
- Remove the food from the oven once cooked. Letting the food to chill in the oven at a temperature below 150 °C results in the forming
of condensation;
- After cooking, leave the oven door partially open to dry out any condensation;
- In case humidity formed inside the oven, we suggest you to treat with neutral vaseline the inside part of the cast iron door.
- Repeat the treatment with the neutral vaseline on the inside part of the cast iron door every 3-6 months, depending of the frequency
of the use of the oven;
- In case of presence of rust on the inside part of the cast iron door, remove the rust by using abrasive material and then treat the cast
iron surface with neutral vaseline.
In order to ensure the quality of the foods that are cooked in the oven, the internal parts of the cast iron doors have NOT been treated with
any product.
12.14. CLEANING OF THE COLLECTION CASING COOKING through the oven
The smokes collection casing can be cleaned either through the oven (remove the horizontal sheet metal which is the base of the oven
See Picture 9 at page 67) the cooker or from the top.
To this purpose remove the circles of the cooking plate and disassemble the smokes pipe from the exhaust small trunk. Cleaning can be
made with a brush and a vacuum cleaner.
IMPORTANT: please verify that the deectors are set as indicated in the Picture.
Pay ATTENTION that after cleaning all dismounted parts are reinstalled hermetically.
13. CALCULATION OF THE THERMAL POWER
There is not an absolute rule for calculating the correct necessary power. This power is given according to the space to be heated, but it
depends also largely on the insulation. On an average, the caloric value necessary for a properly insulated room is 30 kcal/h per m
3
(for
an external temperature of 0°C).
Given that 1 kW corresponds to 860 kcal/h, it is possible to adopt a value of 35 W/m
3
.
Let’s suppose one wishes to heat a room of 150 m
3
(10 x 6 x 2.5 m) in an insulated apartment. In this case, it is necessary to have 150 m
3
x 35 W/m
3
= 5250 W or 5,25 kW. As main heating, a 8 kW device is therefore sufcient.
Approximate combustion value Required quantity in relation to 1 kg of dry
wood
Fuel Unit kcal/h kW
Dry wood (15% humidity) kg 3600 4.2 1,00
Wet wood (50% humidity) kg 1850 2.2 1,95
Wood briquettes kg 4000 5.0 0,84
Brown coal briquettes kg 4800 5.6 0,75
Normal anthracite kg 7700 8.9 0,47
Coke kg 6780 7.9 0,53
Natural gas m
3
7800 9.1 0,46
Naphtha L 8500 9.9 0,42
Electricity kW/h 860 1.0 4,19
12.12. CAST IRON COOKING PLATE AND RINGS
IMPORTANT: to avoid rust DO NOT forget pots or pans on the cold cooking plate. This would create rust rings, unpleasant to see and
difcult to remove.
The cast iron cooking plate and the cast iron rings needs to be periodically cleaned by using sandpaper (grain 150) without touching
the enamelled parts..
To carry out the cleaning operation remove the smoke outlet spigot and the smoke pipe. The smoke compartment can be cleaned from the
front side of the oven (see chap. CLEANING SMOKE COMPARTMENT COOKERS) or from the top. In this case remove the cast iron rings
and the cooking plate, as well the smoke outlet spigot and the smoke pipe. The cleaning can be carried out by using a brush and a hoover.
(Where existing STANLESS STEEL frame) Once you have placed the cast iron cooking plate, make sure to have always 3 mm in-between
the cooking plate and the STAINLESS STEEL frame. This gap is important because of the thermal expansions and to avoid chromatic
changes of the STAINLESS STEEL frame when hot.
ATTENTION: once the cleaning operations are terminated all the parts have to be re-assembled hermetically.
