rOSa - rOSEtta Bii - rOSEtta SiniStra Bii
1095080 21
8. AIR FLOW IN THE PLACE OF INSTALLATION DURING COMBUSTION
As the product draw their combustion air from the place of installation, it is MANDATORY that in the place itself, a sufcient quantity of air
is introduced. If windows and doors are airtight (e.g. built according to energy saving criteria), it is possible that the fresh air intake is no
longer guaranteed and this jeopardises the draught of the appliance and your health and safety. It is therefore necessary to guarantee a
supply of fresh air through an external air inlet placed near the appliance or by placing piping for combustion air which leads outside or to
a nearby airy place, with the exception of the boiler room or garage (FORBIDDEN).
The intake of air for combustion in the place of installation must not be obstructed during operation of the product. It is absolutely essential
that in environments in which products are operated with a natural chimney draught, as much air as is necessary for combustion is
introduced, i.e. up to 20 (<11kW) m³/hour. The natural recirculation of air must be guaranteed by some xed openings to the outside. Their
size is established by regulations regarding the subject. Ask for information from a chimneys weep. The openings must be protected with
grills and must never be blocked up. An extractor hood (suction) installed in the same room or in a neighbouring one causes a depression in
the environment. This causes the leakage of burnt gas (dense smoke, smell); it is therefore necessary to ensure a greater ow of fresh air.
The depression of an extractor hood can, in the worst case scenario, transform the ue of the product into an external air inlet,
re sucking the ue gases into the environment with very serious consequences for persons.
9. ALLOWED / NOT ALLOWED FUELS
Allowed fuels are logs. Use exclusively dry logs (max. content of water 20%). Maximum 3 logs should be loaded. The pieces of wood
should have a length of ca. 20-30 cm and a maximum circumference of 30-35 cm.
Compressed not worked-out wood briquettes must be used carefully to avoid overheating that may damage the device, since
these have a very high caloric value.
The wood used as fuel must have a humidity content lower than the 20% and must be stored in a dry place. Humid wood tends to burn
less easily, since it is necessary a greater quantity of energy to let the existing water evaporate. Moreover, humid content involves
the disadvantage that, when temperature decreases, the water condensates earlier in the hearth and therefore in the stack causing a
remarkable deposit of soot with following possible risk of re of the same.
Fresh wood contains about 60% of H
2
O, therefore it is not suitable to be burnt.
It is necessary to place this wood in a dry and ventilated place (for example under a roong) for at least two years before using it.
Besides others, it is not possible to burn: carbon, cuttings, waste of bark and panels, humid wood or wood treated with paints,
plastic materials; in this case, the warranty on the device becomes void.
Paper and cardboard must be used only to light the re.
The combustion of waste is FORBIDDEN and would even damage the appliance and the ue, causing health damages and claims by
the neighborhood owing to the bad smell.
The wood is not a fuel which allows a continuous operation of the appliance, as consequence the heating all over the night is not possible.
Variety kg/mc kWh/kg moistness 20%
Beech
750 4,0
Oak
900 4,2
Elm
640 4,1
Poplar
470 4,1
Larch*
660 4,4
Spruce*
450 4,5
Scots pine *
550 4,4
* RESINOUS WOOD NOT SUITABLE FOR THE BURNING
ATTENTION : the continuous and protracted use of aromatic wood (eucalyptus, myrtle etc.) quickly damages the cast iron parts
(cleavage) of the product.
The declared technical data have been achieved by burning beech wood class “A1” according to the requirement UNI EN ISO 17225-5
and wood moisture content less than 20%. By burning a different kind of wood the efciency of the product itself could change and some
specic adjustments on the appliance could be needed.
10. LIGHTING
WARNING: After the rst ignition you can smell bad odours (owing to the drying of the glue used in the garnitures or of the paint) which
disappear after a brief using of the appliance. It must be ensured, in any case, a good ventilation of the environment. Upon the
rst ignition we suggest loading a reduced quantity of fuel and slightly increasing the caloric value of the equipment
To perform a correct rst lighting of the products treated with paints for high temperature, it is necessary to know the following information:
• the construction materials of the involved products are not homogeneous, in fact there are simultaneously parts in cast iron, steel,
refractory material and majolica;
• the temperature to which the body of the product is subject is not homogeneous: from area to area, variable temperatures within the
range of 300°C - 500°C are detected;
• during its life, the product is subject to alternated lighting and extinguishing cycles in the same day, as well as to cycles of intense use
or of absolute standstill when season changes;
