La Nordica Monoblocco 800 Angolo DX [21/76] Low emission fire lighting

MONOBLOCCO 800 ANGOLO

6098401 21

10. LIGHTING

After the rst ignition you can smell bad odours (owing to the drying of the glue used in the garnitures or of the paint) which disappear after

a brief using of the appliance. A good ventilation of the room should always be guaranteed.

T light the re, it is suggested to use small wood pieces together with paper or other traded lighting means.

It is FORBIDDEN to use any liquid substance as for ex. alcohol, gasoline, oil and similar.

Open the primary air completely.

When wood starts to burn, it is possible to feed it again by opening slowly the door, in order to avoid leaks of smoke, and close the

• the construction materials of the involved products are not homogeneous, in fact there are simultaneously parts in cast iron, steel,

refractory material and majolica;

• the temperature to which the body of the product is subject is not homogeneous: from area to area, variable temperatures within

the range of 300°C - 500°C are detected;

• during its life, the product is subject to alternated lighting and extinguishing cycles in the same day, as well as to cycles of intense

use or of absolute standstill when season changes;

• the new appliance, before being considered seasoned has to be subject to many start cycles to allow all materials and paints to

complete the various elastic stresses;

• in detail, initially it is possible to remark the emission of smells typical of metals subject to great thermal stress, as well as of wet

paint. This paint, although during the manufacture it is backed at 250 °C for some hours, must exceed many times and for a given

3. Repeat this operation for at least 4-5 or more times, according to your possibilities.

4. Then load more and more fuel (following in any case the provisions contained in the installation booklet concerning maximum load)

and, if possible, keep the lighting periods long avoiding, at least in this initial phase, short ON/OFF cycles.

5. During the rst starts, no object should be leaned on the appliance and in detail on enamelled surfaces. Enamelled surfaces must

not be touched during heating.

6. Once the «break-in» has been completed, it is possible to use the product as the motor of a car, avoiding abrupt heating with

excessive loads.

After testing the proper working of the appliance, some days from the installation, it is possible to proceed with the construction

of its aesthetic covering.

WARNING: During the surround building operations it must kept in mind possible and subsequent electrical installed parts maintenance

smallest at the top, or vertically in the case of tall narrow combustion chambers. Place the re starter module on top of the pile, arranging

the rst logs in the module at right angles to the pile of wood.

Fire STARTER MODULE

This re starter module replaces a paper or cardboard starter.

Prepare four logs, 20 cm long with a cross section of 3 cm by 3 cm Picture 16 at page 65. Cross the four logs and place them on top of the

pile of wood at right angles, with the re lighter (wax impregnated wood bre for example) in the middle. The re can be lit with a match.

If you want, you can use thinner pieces of wood. In this case, you will need a larger quantity.

Keep the ue gas exhaust valve and combustion air regulator open (1A - 2A). After lighting the re, leave the combustion air regulator

open in the position shown in the Picture 16 at page 65.

IMPORTANT:
