Mitsubishi Electric SLZ-KF35VA / SUZ-KA35VA5 [10/28] Care and cleaning

5. Care and Cleaning

► Cleaning the ﬁ lters

• Clean the ﬁ lters using a vacuum cleaner. If you do not have a vacuum

cleaner, tap the ﬁ lters against a solid object to knock off dirt and dust.

• If the ﬁ lters are especially dirty, wash them in lukewarm water. Take care

to rinse off any detergent thoroughly and allow the ﬁ lters to dry completely

before putting them back into the unit.

Caution:

• Do not dry the ﬁ lters in direct sunlight or by using a heat source,

such as an electric heater: this may warp them.

• Do not wash the ﬁ lters in hot water (above 50°C), as this may warp

them.

• Make sure that the air ﬁ lters are always installed. Operating the unit

without air ﬁ lters can cause malfunction.

Caution:

• Before you start cleaning, stop operation and turn OFF the power

supply.

• Indoor units are equipped with ﬁ lters to remove the dust of sucked-

in air. Clean the ﬁ lters using the methods shown in the following

sketches.

► Filter removal

Caution:

• In removing the ﬁ lter, precautions must be taken to protect your

eyes from dust. Also, if you have to climb up on a stool to do the

job, be careful not to fall.

• When the ﬁ lter is removed, do not touch the metallic parts inside

the indoor unit, otherwise injury may result.

■ SLZ-KA·VAQ3/SLZ-KA·VAL3

1 Pull the knob on the intake grille in the direction indicated by the arrow

and it should open.

2 Open the intake grille.

3 Release the knob on the center edge of the intake grille and pull the

ﬁ lter forward to remove the ﬁ lter.

A Knob B Grille C Intake grille D Filter








