Hoshizaki IM-100WNE [24/92] Top panel
![Hoshizaki IM-100WNE [24/92] Top panel](/views2/1322676/page24/bg18.png)
20
[c] IM-45CNE (Air-cooled)
Air-Cooled Condenser
Top Panel
Louver
Bin Door
Water Plate
Evaporator
Water Valve
Bin Control Switch
Hot Gas Valve
Power Cord
Control Box
Compressor
Fan Motor
Actuator Motor
Drain Pan
Pump Motor
Water Tank
Front Panel (Lower)
Air Filter
Handle
Drain Pipe
Front Rear
Front
Nameplate
