25
IM-100WNE, 130WNE (Water-cooled)
Front
Rear
Front Front
Top Panel
Handle
Front Cover Low
Door
Nameplate
Water Valve
Power Cord
Drain Pi
p
e
Cooling Water Inlet
Cooling Water Outlet
Control Box
Slope
Evaporator
Actuator Motor
Water Tank
Bin Control Switch
Pump Motor
Drain Pan
Hot Gas Valve
Compressor
Water-cooled Condenser
Water Regulator
[h] IM-100WNE, IM-130WNE (Water-cooled)
