![Compak R8 [10/21] Where to use](/views2/1335827/page10/bga.png)
ORIGINAL INSTRUCTIONS | Ref. quality process 002/03 | v. 18/07/2016 | K04673
8
7.3. Where to use
The grinder should be installed on a at, stable surface. The minimum
dimensions of the work space should be as follows:
Model
R8, R80, R100 R120, R140
Height
28.35
720
35.43
900
in
mm
Width
9.45
240
10.43
265
in
mm
Depth
13.78
350
16.34
415
in
mm
7.4. Grinder installation
Before grinder installation, the following should be considered:
• The grinder information plaque data coincides with the electrical system on
site.
• The electrical outlet coincides with the grinder plug.
• The electric power at the location of installation should meet the minimum
required to properly run the grinder.
• The installation site should have the proper electrical overload protections.
• The grinder should be properly grounded as specied by local code.
The three-phase models are sold without the plug. In these models, you will be given
an uncovered power cable.
