8.2. Hopper placement

Remove the upper body ( ) by unscrewing the two screws on the backside of the

grinder.

Place the hopper ( ) on the upper body and make sure that the hinge of the hopper

lid ( ) lines up with the backside of the grinder. Push down and turn clockwise until

the hopper clicks into place on the upper body ( ) (Fig. 4 & 5).

Turn the upper body around and x the hopper to the grinder body with the safety

screw that comes along with the grinder (Fig. 3).

NOTE: The manufacturer cannot accept responsibility for any damage casued by

improper use of the machine.

8.3. Use

Open the hopper lid ( ), ll the hopper ( ) with coffee and close the lid. Once the

coffee is inside the hopper, it can not be removed.

Press the bag support handle ( ) and put the empty bag around the coffee discharge

tube ( ), then release the handle so the bag remains xed in place.
