ISA Pastryshow 120 A [12/32] Disposal of waste material
![ISA Pastryshow 120 A [12/32] Disposal of waste material](/views2/1335858/page12/bgc.png)
12
PASTRYSHOW 2
USE AND MAINTENANCE MANUAL
428000514037
EN
7. DISPOSAL OF WASTE MATERIAL
During normal operation, the appliance does not generate any environmental contamination. At the
end of its life cycle, or if it is necessary to proceed to permanent decommissioning, we recommend
following the procedures below:
DISPOSAL (User)
The symbol on the product or the package indicates that the product must not be considered normal
domestic waste but must be taken to an appropriate collection centre for the recycling of electrical and
electronic equipment. Proper disposal of this product prevents negative consequences which could be
caused by inadequate product disposal. For more detailed information on recycling this product, contact
the municipal offi ce, the local waste disposal service or the shop where the product was purchased.
PROCEDURE FOR DISPOSAL and RECYCLING AT END-OF-LIFE
(Authorised Organisations)
• Switch off the equipment and unplug the power supply cable.
• Remove the lamps (if installed). These should be disposed of separately.
• Remove the power units and the electronic cards. These should be disposed of separately.
• Remove all the independent parts (grids, casings, profi les, etc.) and group them according to
shared features in order to access the heat exchangers, pipes, cables, etc. and be careful not to
damage the cooling circuit.
• Remove all mobile parts (doors, sliding doors, glass parts, etc.) and group the various materials
according to their features.
• Check the type of coolant on the plate fi tted inside the cabinet; empty the coolant and dispose of
it through authorised waste centres
• Disconnect the evaporator, the condenser, the compressor, the piping and the fans. These are
made of copper, aluminium, steel and plastic and should therefore be disposed of separately.
• Upon removal of all guards and the various components from the frame, separate the different
types of material making up the appliance (plastic, sheet steel, polyurethane, copper, etc) and
collect them separately.
All recyclable materials and waste should be processed and recycled by professionals, in compliance
with the laws in the country in question.
The company responsible for recycling the materials should be registered and certifi ed as a waste
disposal service in accordance with the country in question
Attention
Illegal disposal of the product by the owner will result in administrative sanctions as required by
current laws.
Disposal of the product should comply with current laws on the disposal of
coolant liquids and mineral oils.
Important
If the crossed out wheelie bin sign is not present on the appliance, it means that the disposal of the
product is not the manufacturer's responsibility. In that case, always follow the current laws on waste
disposal.
Supplementary information
Further information on the methods for disposing of liquid refrigerants and oils and other substances
can be found on the safety data sheet for the substance itself.
