ISA Zero T12 VT SP [25/40] Technical specifications
![ISA Zero T12 VT SP [25/40] Technical specifications](/views2/1335877/page25/bg19.png)
EN
USE AND MAINTENANCE MANUAL
428000730
037
25
ZERO PROGEL
11. TECHNICAL SPECIFICATIONS
T8 OR
External dimensions
Lenght mm 1435
Depth mm 790
Height mm 870
Weight (net) Kg 190
T5
External dimensions
Lenght mm 800
Depth mm 700
Height mm 920
Weight (net) Kg 120
T8
External dimensions
Lenght mm 800
Depth mm 700
Height mm 1270
Weight (net) Kg 180
T12
External dimensions
Lenght mm 800
Depth mm 700
Height mm 1750
Weight (net) Kg 210
T16
External dimensions
Lenght mm 800
Depth mm 700
Height mm 1950
Weight (net) Kg 240
