ISA Zero T12 VT SP [30/40] Installation
![ISA Zero T12 VT SP [30/40] Installation](/views2/1335877/page30/bg1e.png)
30
EN
428000730037
USE AND MAINTENANCE MANUAL
ZERO PROGEL
11.3 INSTALLATION
Attention
t is fundamental to respect the distances indicated (mm) for correct installation of the appliance.
11.4 LOAD LIMITS
Attention
It is fundamental not to exceed the load limits
indicated in order not to alter the correct air
circulation and thus prevent a high product
temperature.
The limits given refer to a static load and evenly distributed.
Are therefore excluded dynamic overloads due to loading operations violent, ranging absolutely
avoided for safety reasons.
