2 CJ-981E

Printed in Japan / Imprimé au Japon / Gedruckt in Japan / Stampato in Giappone

Clarion Co., Ltd.

CJ-981E

280-8293-00

2005/7 (A·K)

Be sure to unfold and read the next page.

Veuillez déplier et vous référer à la page suivante.

Bitte ausbreiten und die nächste Seite lesen.

Assicurarsi di aprire e leggere la pagina successiva.

6.5 LCD Color Monitor for Rear-View

Vehicular Camera Systems

Écran LCD couleur de 6,5 pouces pour

système rétro caméra automobile

6,5-Zoll-LCD-Farbmonitor für Fahrzeug-

Heckkameraanlagen

Monitor LCD a colori da 6,5” per telecamere

di retrovisione per automobili

Owner’s manual & Installation manual

Mode d’emploi et manuel d’installation

Bedienungs- & Installationsanleitung

Manuale d’Istruzioni e d’Installazione

CJ-981E

ADJ

POWER

SELECT

IRIS

ZOOM

CAM1/DIM

FUNC

MODE

English

DeutschFrançais

Italiano

English

Thank you for purchasing this Clarion product.

∗ Please read this owner’s manual in its entirety before operating this equipment.

∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).

∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.

1. FEATURES

■ 6.5" TFT active-matrix-drive wide color-

LCD display

■ Reverse-gear linked display

When used to confirm the rear view, the monitor

can be set so that the rear view camera is

automatically selected when the vehicle’s

transmission is shifted to reverse gear.

■ Automatic Screen Saver Function

In manual mode (CAM mode), a timer can be

set to automatically turn off the screen after a

preset interval, thus helping preserve the

monitor.

■ Scale Marker Display

When using the camera image to confirm

safety, scale marks displayed onscreen assist

the driver in determining distances to obstacles.

■ Backlight compensation function

The camera’s aperture (iris) can be adjusted

to provide brighter viewing under adverse

backlighted conditions (e.g., when vehicle

shadow is cast in the camera path or when

entering a garage).

■ Screen brightness (DIMMER) linked to

parking lamp switch

■ Supports use of CC-2000 series digital

1.4x zoom CCD cameras

Supports zoom function for 1.4x magnification

of image.

■ Supports DC 24V or DC 12V vehicles

Voltage can be switched at power supply box.

■ Auxiliary input (power supply box VIDEO/

IN) connector

Can be used to view images from sources

other than a camera (to prevent driver

distraction, auxiliary video images cannot be

viewed when vehicle is moving).

■ Image controls

Image adjustment controls include BRIGHT

(luminance), HUE (tint), COLOR (saturation),

and DIMMER.

■ Three camera input (power supply box

CAMERA/IN) connectors

An additional two cameras can be connected

in addition to the rear-view camera.

■ RGB video input (power supply box RGB/

IN) connectors

Allows viewing of images from an auto

navigation system, etc.

Contents

1. FEATURES ............................................. 2

2. NAMES AND FUNCTIONS OF PARTS ... 3

3. PRECAUTIONS ...................................... 5

Handling Precautions ............................... 5

4. OPERATIONS .......................................... 7

Adjusting the Image Quality ..................... 7

Selecting VTR Playback Mode

(NTSC/PAL) ..............................................7

Setting the Camera Function

(CAM TYPE) ............................................. 7

To Display Onscrren Scale Markers

(MARKER) ................................................8

Setting the Marker Pattern

(MARKER SELECT) .................................8

Adjusting the Bumper Position

(MARKER ADJUST) ................................. 9

Setting the Screen Saver

TIMER Function ..................................... 10

Setting the Camera Linked-Image Switch

(CAM AUTO/CAM HAZARD) ................. 10

Enlarging the CCD Camera’s Image

(ZOOM Function) ................................... 11

Backlight Compensation Function

(IRIS) ...................................................... 11

Using the Dimmer Function (DIM) .......... 12

To Immediately Switch to

CAMERA1 Image ................................... 12

5. INSTALLATION ...................................... 13

Before Installing ...................................... 13

Installing the Monitor Stand/Display Unit ...

6. TROUBLRSHOOTING ........................... 15

7. SPECIFICATIONS ................................. 15
