3-1. Press the [SELECT] (z) button to choose

either “ON” or “OFF”.

• ON: camera display is automatically linked

to the circuit operation.

• OFF: camera display is not automatically

linked to the circuit operation.

Hazard Switch Linked Switching

• CAMERA2 Hazard-Switch Linked Display

(CAM2 HAZARD)

When the power supply box’s CAMERA2 link

wire has been wired to the vehicle’s left-turn

signal wire, this setting determines whether

the CAMERA2 image signal is automatically

displayed when the vehicle’s hazard switch is

activated.

• CAMERA3 Hazard-Switch Linked Display

(CAM3 HAZARD)

When the power supply box’s CAMERA3 link

wire has been wired to the vehicle’s left-turn

signal wire, this setting determines whether

the CAMERA3 image signal is automatically

displayed when the vehicle’s hazard switch is

activated.

3-1. Press the [SELECT] (z) button to choose

either “ON” or “OFF”.

• ON: camera display is not automatically

linked to the circuit operation.

• OFF: camera display is automatically

linked to the circuit operation.

Note:

• If the CAMERA2 and CAMERA3 link wires are

wired to a circuit other than the turn-signal, set

both “CAM2 HAZARD” and “CAM3 HAZARD” to

“OFF”.

4. Press the [MODE] button to return to the

“CAM” mode screen.

Enlarging the CCD Camera’s

Image (ZOOM Function)

This function operates only when a zoom-

equipped CCD camera is connected, and when

the “CAM TYPE” setting has been used to

select a zoom-equipped camera.

1. Press the [ZOOM] button.

The CCD camera’s image is enlarged by a

ratio of 1.4x. During operation of the zoom

function the word “ZOOM” will appear in the

upper left corner of the screen.

2. To return to the normally sized image, press

the [ZOOM] button once again.

Backlight Compensation

Function (IRIS)

Under conditions of backlight, it may become

difficult to visually confirm on screen the position

of the bumper or people and objects in the

vicinity of the vehicle. In such cases, this

function automatically adjusts the size of the

CCD camera’s aperture (iris) to allow for easier

viewing conditions.

1. Press the [IRIS] (w) button.

The CCD camera’s aperture is automatically

adjusted to produce a brighter image.

2. To return to the normal aperture, press the

[IRIS] (w) button once again.

Notes:

• When the backlight compensation function

operates, the entire monitor screen will become

brighter, with the result that bright areas

recognizable under normal conditions may

become excessively washed out and more

difficult to see.

Do not use the backlight compensation function

except for temporarily improving visibility of dark

areas of the screen.

• The backlight compensation function operates

when the connected CCD camera is

manufactured by Clarion.
