12 CJ-981E

English

Using the Dimmer Function

(DIM)

When the power supply box’s parking-lamp

switch wire is wired to the vehicle’s parking lamp

switch, the screen is dimmed automatically for

ease of viewing whenever the parking lamp

switch is activated.

1. Hold the [CAM1/DIM] switch depressed for

about 1 second to switch the dimmer

between Light/Dark.

2. In the event that parking lamps are used

during the daytime, making the screen too

dark, hold the [CAM1/DIM] button depressed

for about 1 second (the “DIM” message will

not appear on the screen). Hold the button

depressed once again (about 1 second) to

return to the ordinary dimmed screen (the

indicator “DIM” will once again appear at the

top of the screen).

3. To dim the screen when the parking lamps

are OFF, hold the [CAM1/DIM] button

depressed for about 1 second (the “DIM”

message will appear on the screen). Hold

the button depressed once again (about 1

second) to return to the ordinary bright

screen.

Notes:

Regarding dimmer function when ignition switch

ACC is moved from OFF to ON.

• If parking lamp switch is OFF, the screen will

appear bright.

• If the parking lamp switch is ON, the screen will

appear dimmed.

To Immediately Switch to

CAMERA1 Image

If the screen image has turned off or images

from other sources (CAMERA2, CAMERA3,

VTR, RGB) are currently showing, you can

switch immediately to the CAMERA1 image with

a single button press:

1. Press the [CAM1/DIM] button.
