Installing the Keyboard

1. Adhere the Mylar to the keyboard.

2. Align the screw holes on the keyboard with the screw holes on the palm-rest assembly.

3. Replace the screws that secure the keyboard to the palm-rest assembly.

4. Adhere the Mylar to the screws that secure the keyboard to the palm-rest assembly.

5. Connect the keyboard cable and keyboard-backlight cable to the keyboard-controls board.

6. Install the:

a. system board

b. hard drive

c. base cover

7. Follow the procedures in After Working Inside Your Computer.

Removing the Display Assembly

1. Follow the procedures in Before Working Inside Your Computer.

2. Remove the:

a. base cover

b. battery

3. Perform the following steps:

a. Disconnect the left LVDS cable [1].

b. Remove the screw securing the metal bracket [2] and lift the bracket off the computer [3].

c. Disconnect the right LVDS cable from the system board [4].
