Additional information12
114
En
Professional Calibration EQ graphical output
Display
Symptom Remedy
The EQ response displayed in
the graphical output
following calibration does not
appear entirely flat.
• There are cases where the graph does not appear flat (even when selecting
ALL CH ADJ in the Auto MCACC Setup) due to adjustments made to
compensate for room characteristics to achieve optimal sound.
• Areas of the graph may appear identical (before and after) when there is little
or no adjustment needed.
• The graph may appear to have shifted vertically when comparing before and
after measurements.
EQ adjustments made using
the Manual MCACC setup on
page 90 do not appear to
change the graphical output.
• Despite level adjustments being made, the filters used for analysis may not
display these adjustments in the graphical output. However, these adjustments
are taken this into account by the filters dedicated to overall system calibration.
Lower frequency response
curves do not seem to have
been calibrated for SMALL
speakers.
• Low frequencies used in bass management (the subwoofer channel) will not
change for speakers that have been specified as SMALL in the configuration,
or do not output these frequencies.
• Calibration is performed, but due to your speakers’ low frequency limitations,
no measurable sound is output for display.
Symptom Remedy
The display is dark or off. • Press DIMMER repeatedly to select a different brightness.
After making an adjustment
the display goes off.
• Press DIMMER repeatedly to select a different brightness.
You can’t get DIGITAL to
display when using SIGNAL
SEL.
• Check the digital connections and make sure that the digital inputs are
assigned correctly (see The Input Setup menu on page 42).
2 DIGITAL or DTS does not
light when playing Dolby/DTS
software.
• These indicators do not light if playback is paused.
• Check the playback (especially the digital output) settings of the source
component.
When playing Dolby Digital
or DTS sources, the receiver’s
format indicators do not light.
• Check that the player is connected using a digital connection.
• Make sure that the receiver is set to AUTO or DIGITAL (see Choosing the
input signal on page 61).
• Check that the player isn’t set up so that Dolby Digital and DTS sources are
converted to PCM.
• Ensure that if there are several audio tracks on the disc, the Dolby Digital or
DTS is selected.
When playing certain discs,
none of the receiver’s format
indicators light.
• The disc may not contain 5.1/6.1 channel material. Check the disc packaging
for more on what audio tracks are recorded on the disc.
When playing a disc with the
listening mode set to Auto
Surround or ALC, 2 PL II or
Neo:6 appear on the receiver.
• Make sure that the receiver is set to AUTO or DIGITAL (see Choosing the
input signal on page 61).
• If a two channel soundtrack is currently playing (including Dolby Surround
encoded), then this is not a malfunction. Check the disc packaging for details
about the audio tracks available.
VSX-1020_SYXCN.book 114 ページ 2010年3月12日 金曜日 午前9時10分
