User Manual of 4-inch High Speed Dome

ADJUST BLANK POS

FOCUS+SHIFT STATUS

SAVE: OPEN

QUIT: CLOSE

Figure 3-8 Set the Privacy Mask

(2) You can see ADJUST BLANK POS message on the screen. Click the direction buttons to adjust

the position of the privacy mask to the designed scene.

(3) Click FOCUS+ button, and you can see ADJUST BLANK SIZE message on the screen. Click the

up/down buttons to increase/decrease the height of the mask and click right/left buttons to

increase/decrease the width of the mask. Click IRIS+ button to save the settings and return

to the previous menu and you can see the mask turn to gray.

(4) To modify the configured mask, click IRIS+ button to enter the SET BLANK menu and click

IRIS+ button again to modify.

Note: The tilt range for configuring the privacy masks is from 0° to 70°.

4. Enable or disable the privacy mask function.

Enter the BLANK STATUS submenu and click the up and down direction buttons to set it ON or

OFF.

Note: If no privacy mask has been configured, you cannot set the status as ON.

5. Delete the privacy mask.

You can enter the CLEAR BLANK menu to delete the current privacy mask.

3.3.3 Configuring OSD Settings

Purpose:

You can configure the on-screen display of the dome name, PTZ control information, viewing

direction, etc.

 Display the dome title

Steps:

1. Enter the dome title setting menu:

MAIN MENUS > SET TITLE

2. Click IRIS+ to enter the editing mode.

3. Click FOCUS + to set it to ON.

4. Click IRIS+ again to confirm.

5. Exit the MAIN MENUS interface.

6. On the live view screen, call preset 11 twice within 5 seconds to enter the SET TITLE menu, as

shown in the following figure.
