User Manual of 4-inch High Speed Dome

Task 2: Preview the task.

Move the cursor to TASK PREVIEW and click IRIS+ to view the time, action and status of the

scheduled task.

NUM TIME ACTION STATE

1 WHO 0 0 0 0 NONE OFF

2 WHO 0 0 0 0 NONE OFF

3 WHO 0 0 0 0 NONE OFF

4 WHO 0 0 0 0 NONE OFF

5 WHO 0 0 0 0 NONE OFF

6 WHO 0 0 0 0 NONE OFF

7 WHO 0 0 0 0 NONE OFF

8 WHO 0 0 0 0 NONE OFF

Figure 3-22 Preview the Time Task

Task 3: Delete the task.

Move the cursor to CLEAN TASK and click IRIS+ to delete the time and action of the current task.

3.4.6 Configuring Zones

Purpose:

ZONE submenu is used to divide the scene into several parts with user-defined labels displayed on

the screen. You can also set the speed dome to scan in a zone automatically after a period of

inactivity.

Task 1: Set a zone.

Steps:

1. Move the cursor to enter the zone configuration submenu:

MAIN MENUS > DOME SETTINGS > ZONES

ZONES

ZONE NUM 1

[UNDEFINED ]

EDIT LABEL

EDIT ZONE

ZONE STATUS ON

SCAN STATUS ON

CLEAR ZONE

BACK EXIT

Figure 3-23 Zone Configuration

2. Choose the zone number:

Move the cursor to ZONE NUM and click IRIS+ button to enter. Click the up and down buttons to

choose the zone number to be configured.
