User Manual of 4-inch High Speed Dome

Figure 3-13 Preset Configuration Menu

2. Choose the preset number:

Move the cursor to PRESET NUM and click IRIS+ to enter. Click the up and down buttons to

choose the preset number which needs to be edited. If the preset has been defined, the preset

label will be listed under the number; if it has not been defined, you will see [UNDEFINED]

under the number.

Notes:

 There are up to 254 presets can be set for the speed dome.

 The system-defined presets will be displayed on this submenu and they are not editable.

3. Edit the label of the preset.

LABLE [PRESET 1 ]

INS

ZOOM+DELETE CONTENTS

FOCUS+CHANGE CONTENTS

FOCUS-CHANGE MARKER

ROCKER CHOOSE CONTENTS

OPEN: SURE CLOSE: BACK

Figure 3-14 Edit the Preset Label(1)

Steps:

(1) Move the cursor to EDIT LABLE and click IRIS+ to enter the edit mode.

(2) Click FOCUS+ in the PTZ control panel to switch between the character lists, including capital

alphabet, lowercase alphabet, symbols and numbers; click the up/down and left/right

direction buttons to move the cursor to choose a specific character to input.

(3) Click FOCUS- to position the cursor on the label where the character needs to be modified.

Click ZOOM IN to delete it.

(4) Click IRIS+ to select the character from the letter/number/symbol list to the label.

(5) Click FOCUS+ to exit the character lists and click IRIS+ again to confirm and exit the

submenu.

LABEL [PRESET 1 ]

INS

LOWCASE[a b c d e f g h I j]

ZOOM+DELETE CONTENTS

FOCUS+CHANGE CONTENTS

FOCUS-CHANGE MARKER

ROCKER CHOOSE CONTENTS

OPEN: SURE CLOSE: BACK

Figure 3-15 Edit the Preset Label(2)

4. Set the preset position.
