AXIS P1346/-E/AXIS P1347/-E - Accessing the Camera

Pan/Tilt/Zoom controls

The following controls are available if PTZ is enabled, see View Areas, on page 20. The administrator can enable and disable

the controls for specific users under System Options > Security > Users > User List.

Use the slider to control the volume of the speakers and the microphone.

Half-duplex mode

The Talk/Listen button is used to switch between sending and receiving audio. The button can be config-

ured from the Audio tab in the AMC Control panel:

• Push-To-Talk mode: Click and hold the button to talk/send, release the button to listen.

• Toggle mode: Click once to switch between talking and listening.

Simplex – Network Camera speaker only mode

To send audio, the Talk and Microphone buttons must both be enabled. Click either button to stop audio

transmission.

Click the Emulate joystick mode button and click in the image to move the camera view in the direction of the

mouse pointer.

Click the Center mode button and click on a position in the image to center the camera view on that position.

Pan, Tilt and Zoom bars — Clicking a position directly on the bar moves the camera view directly to the new posi-

tion in one smooth movement. Clicking on the arrows at the ends of a bar causes an incremental change. Clicking

Home will set the camera to the minimum zoom position. In this position, the camera cannot pan or tilt.

Click the Ctrl panel button to open the PTZ control panel which provides additional PTZ controls.

User-defined buttons can also appear in the Control panel, see Advanced, on page 28.
