![Axis P3343-VE [25/68] Live view layout](/views2/1372490/page25/bg19.png)
25
AXIS P33 Series - Live View Config
Live View Layout
Stream Profile
From the Stream Profile drop-down list, select the stream profile to use for the Live View page. Standard stream profiles are
listed as well as the ones created under Video > Stream Profiles. See the online help files
on this page for more
information
Default Viewer
From the drop-down lists, select the default method for viewing video images for your browser. The camera attempts to show
the video images in the selected video format and viewer. If this is not possible, the camera overrides the settings and selects
the best available combination.
Viewer Settings
Check the Show viewer toolbar box option to display the AXIS Media Control (AMC) or the QuickTime viewer toolbar under
the video image in your browser.
The administrator can disable the installation of the H.264 decoder included with AMC. This is used to prevent the installation
of unlicensed copies. Further decoder licenses can be purchased from your Axis dealer.
The Show crosshair in PTZ joystick mode option enables a cross that indicates the center of the image when viewing the
video stream in PTZ joystick mode.
Enable the Use PTZ joystick mode as default option to set the PTZ mode to joystick. The mode can be changed temporarily on
the PTZ Control Panel, but will default to joystick if this is selected.
Check the Enable recording button option to enable recording from the Live View page.
Action Buttons
The Show manual trigger button option manually triggers and stops an event from the Live View page. See Events, on page
29. In AXIS P3346 a manual trigger button can be shown for each view area.
Check the Show snapshot button option to save a snapshot from the video stream. This button is mainly intended for use
with browsers other than Internet Explorer, or when not using AXIS Media Control (AMC) to view the video stream. AMC for
Internet Explorer provides its own snapshot button.
Play audio clip enabled - Enabling the display of the Audio clip drop-down box and Play button in the Live View page allows
users to play a pre-recorded audio clip from the camera. Go to Video & Audio > Audio Clips to work with the audio clips.
Browser Viewer Description
Windows
Internet Explorer
AMC Recommended viewer in Windows Internet Explorer (H.264/Motion JPEG).
QuickTime H.264
Java applet A slower imaging alternative to AMC. Requires one of the following installed on the
client:
• JVM (J2SE) 1.4.2 or higher
• JRE (J2SE) 5.0 or higher
Still image Displays still images only. Hit the Refresh button in your browser to view a new
image.
Other browsers
Server Push Recommended viewer for other browsers (Motion JPEG).
QuickTime H.264
Java applet A slower imaging alternative to Server Push (Motion JPEG only).
Still image Displays still images only. Hit the Refresh button in your browser to view a new
image.
