AXIS P33 Series - System Options

Storage - Disk Management

Disk Management is used to setup and manage local storage devices. Local storage can be used to save video streams from

triggered, scheduled or continuous recordings. For information on how to use the local storage with Triggered and Scheduled

Event Type Setup and Continuous Recordings see the online help

Storage Device

Once a formatted SD card has been inserted in the SD memory card slot, it is automatically mounted and information such as

the available space and the size of the storage device is shown. The disk is full when there is less than 1000KB of space left on

the memory card.

The memory card must be formatted to be mountable. Mounting is done automatically when a new memory card is inserted,

or when the system boots. The only time you need to do a manual mount, is when you have executed an unmount command

and the memory card has not been ejected and reinserted.

Status shows as follows:

• OK - The storage device is mounted and working correctly

• connected - The storage device is present but not mounted

• disconnected - The storage device is not present.

• failed - A problem has been discovered.

If the status shows as failed, click Check disk to see if the problem can be found and then try Repair. As a final measure the

storage device might need to be reformatted. If there is important data on the storage device, see Troubleshooting, on page

50.

Disks are normally preformatted when purchased, but if for whatever reason you need to...click the Format button to format

the disk. Any previous data stored on the disk will be lost.

Read only shows the status of write-protect tab on the memory card. The status no means the tab is in the write-enabled

mode and recordings can be saved to the memory card. The status yes means the memory card's tab is in the

write-protected/read-only position, or there is a system error and recordings cannot be saved to the memory card.

Important!

To prevent loss of data, click Unmount before removing a storage device.

Storage Device Settings

Storage Device Settings is used to configure removal of recorded video.

Automatic disk cleanup

To avoid filling up local storage, Automatic disk cleanup can be set to continually remove older recordings to create more

space.

Once enabled, automatic disk cleanup can be set to remove recordings that are older than a set number of days or weeks and

when a percentage of the disk is full. For longer or continuous recordings, the oldest part of the recording is removed, it is

recommended to have a time and date overlay in the video for proper tracking of recordings. See Text Overlay Settings, on

page 14.

Note:

For continuous recording to work properly, do not set the limit to more than 95% full.

Interrupted recordings with an Unknown status, partial recordings and any other recording that has not been removed by disk

cleanup can be removed manually from the Recording List using the Remove button.

Check Lock disk to stop writing to the disk and protect recordings from being removed. A locked disk cannot be formatted.
