Axis P3344-VE [40/68] Axis p33 series system options

AXIS P33 Series - System Options

Always - The camera will constantly attempt to connect to the AVHS service over the Internet; once registered the camera

will stay connected to the service. This option can be used when the camera is already installed and it is not convenient to use

the one-click installation.

AXIS Internet Dynamic DNS Service - Use the AXIS Internet Dynamic DNS service to assign a host name for easy access to

your network camera (requires Internet access).

Click Settings... to register the camera with the Axis Internet Dynamic DNS service, or to modify the existing settings (requires

access to the Internet). The domain name currently registered at the Axis Internet Dynamic DNS service for your product can

at any time be removed.

For more information, refer to the online help .

Advanced TCP/IP Settings

DNS Configuration - DNS (Domain Name Service) provides the translation of host names to IP addresses on your network.

Obtain DNS server address via DHCP - Automatically use the DNS server settings provided by the DHCP server. Click the View

button to see the current settings.

Use the following DNS server address - Enter the desired DNS server by specifying the following:

Domain name - Enter the domain(s) to search for the host name used by the network cameras. Multiple domains can be

separated by semicolons (;). The host name is always the first part of a Fully Qualified Domain Name, for example, myserver is

the host name in the Fully Qualified Domain Name myserver.mycompany.com where mycompany.com is the Domain name.

Primary and Secondary DNS servers - Enter the IP addresses of the primary, and secondary DNS servers.

Note:

This is not mandatory with regard to secondary DNS servers.

NTP Configuration - Check the Obtain NTP server address via DHCP radio button to automatically look up and use the

NTP server settings as provided by DHCP. Click the View button to see the current settings.

Use the following NTP server address - To create manual settings, check this radio button and enter the host name or IP

address of the NTP server.

Host Name Configuration - The network cameras can be accessed using a host name, instead of an IP address. The host

name is usually the same as the assigned DNS Name.

For more information, please see Security, on page 36.

Link-Local IPv4 Address - This is enabled by default and assigns the network cameras an additional IP address for use

with UPnP™. The camera can have both a Link-Local IP and a static/DHCP-supplied IP address at the same time - these will

not affect each other.

HTTP and HTTPS - The default HTTP/HTTPS port numbers (80 and 443 respectively) can be changed to any port within the

range 1024-65535. This is useful for simple security port mapping, for example.

NAT traversal (port mapping) for IPv4 - A broadband router allows devices on a private network (LAN) to share a single

connection to the Internet. This is done by forwarding network traffic from the private network to the “outside”, that is, the

Internet. Security on the private network (LAN) is increased since most broadband routers are pre-configured to stop attempts

to access the private network (LAN) from the public network/Internet.
