4.2 PEDAL GRIP ADJUSTMENT HANDLE RWPLACEMENT
1) Loose 4 bolts and take out the grip. (Figure A).
2) Replace Grip and fix the 4 bolts (Figure B).
Figure A Figure B
4.3 ADJUSTMENT GRIP REPLACEMENT
1) Loose the stopper bolts and take out the grip.(Figure A).
2) Replace Grip and fix the 2 bolts (Figure B).
Figure A Figure B
