2.1 G1-MG30 3-STACK MULTI-GYM ASSEMBLY INSTRUCTIONS
UNPACKING G3-MSFT 300lbs/400lbs Multi-Station Functional Trainer
Thank you for purchasing a MATRIX Fitness product. Carefully unpack the unit from this box and
dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the G3-MSFT 300lbs/400lbs Multi-Station 502Ibs (226kg) not including the weight
stack. To avoid injury to yourself and prevent damage to the frame components, be sure to have
proper assistance removing the frame pieces
INCLUDE TOOLS REQUIRED FOR ASSEMBLY
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
Phillips Screwdriver
8MM Open-End Wrench
14MM Open-End Wrench
17MM Open-End Wrench
Guide Rod Lubrication
Hardware Bag
