3.1 TROUBLESHOOTING – CABLE ISSUES
CABLE IS LOOSE
POSSIBLE CAUSES
1. The fix bolts are loosed.
SOLUTION
1. Undo the former fixing nut , then the cable screw should be adjust fronted.(Figure A & B).
2. Lock the fixing nut (Figure C).
CHAPTER
3
: TROUBLESHOOTING
Figure A
Figure B
Figure C
