Basic Operations
28
MAX678RVD
English
Owner’s manual
Setting the anti-theft function
(CATS)
“CATS” is the acronym of “Clarion Anti-Theft
System”.
When you set a PIN code (called as “Personal
Code”), a theft is prevented by disabling the
operation of the unit at the theft.
In addition, set the BLINK LED function in the
GENERAL menu to [ON] to improve the effect of
the CATS function (see page 26).
Setting your Personal Code
1. Press the [ADJ] button, then touch the
[GENERAL] key.
2. Keep pressing the [MENU] button more than
2 seconds.
The SET PERSONAL CODE screen appears.
* When a Personal Code is already set, the
ERASE PERSONAL CODE screen will
appear. Retry this operation after erasing the
old Personal Code.
3. Enter your desired 4-digit Personal Code by
touching the [0] to [9] keys, then touch the
[ENT] key.
* Touch the [CLR] key when you make a
mistake in entering.
4. Enter the same Personal Code again for
confirmation, then touch and hold the [ENT]
key for more than 2 seconds.
The entered Personal Code will be set, and it
will return to the previous screen.
Erasing the Personal Code
1. Press the [ADJ] button, then touch the
[GENERAL] key.
2. Keep pressing the [MENU] button more than
2 seconds.
The ERASE PERSONAL CODE screen
appears.
3. Enter the Personal Code currently set by
touching the [0] to [9] keys, then touch and
hold the [ENT] key for more than 2 seconds.
The message “CODE ERASED” appears,
and it will return to the previous screen.
Note:
• Write down your Personal Code in case you forget
it.
When the ENTER PERSONAL CODE
screen appears
The ENTER PERSONAL CODE screen will be
displayed when turning the power on after
performing the following operations:
• The car battery was replaced.
• The backup power was cut off.
• The Reset button was pressed.
Note:
• If you forgot your Personal Code, please consult
your dealer or an authorized Clarion service
centre.
1. Enter your Personal Code currently set.
2. When the correct Personal Code is entered,
the unit will restart from the initial startup
screen.
Note:
• When you enter a wrong Personal Code, the
message “CODE INCORRECT” is displayed and
the Personal Code entry is prohibited for a while.
This prohibited time is changed according to the
number of times of wrong code entry as follows:
• 1 to 6 times: 15 seconds
• 7 times or more: 15 minutes
