58
MAX678RVD
English
Owner’s manual
TV Operations
TV functions
To watch TV, requires a TV tuner. When an
optional TV tuner is connected through the CeNET
cable, this unit controls all TV tuner functions.
Watching TV
Note:
• For your safety, the MAX678RVD has a safety
function which turns off the picture when the car is
moving, so only the audio can be heard. The
picture can only be watched when the car is
stopped and the parking brake is applied.
1. Press the [SRC] button, and touch the
[TELEVISION] key.
2. Press the [BAND] button or touch the [Band]
key to select the desired TV band (TV1 or
TV2).
Every pressing the button toggles the TV
band between TV1 and TV2.
3. Press the [R] or [F] button to tune in the
previous or next preset TV station.
Watching a video
The TV tuner has a VTR input terminal to which
1 external device can be connected. Connect a
12V video cassette player (VCP) or video
cassette recorder (VCR) to the TV tuner input
terminal.
1. Touch the screen to display the TV/VTR mode
menu, then touch the [Option] key.
2. Touch the [VTR] key to change to the VTR
mode.
• To return to the TV broadcast, perform the
same operation again.
Seek tuning
1. Press the [BAND] button or touch the [Band]
key to select the desired TV band (TV1 or
TV2).
* If “MANU” is displayed in the display, press
and hold the [BAND] button for more than 1
second. “MANU” in the display goes off.
2. Touch the [X] or [x] key to automatically
seek a station.
• Touching the [x] key to tune up the channel
to the next available TV station, and the [X]
key to tune down.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning. When you are in the step tuning
mode, the channel changes one step at a time. In
quick tuning mode, you can quickly tune the
desired frequency.
1. Press the [BAND] button or touch the [Band]
key to select the desired band. (TV1 or TV2)
* If “MANU” is not displayed in the display, keep
pressing the [BAND] button more than 1
second. “MANU” appears and manual tuning is
now available.
2. Tune into a station.
Quick tuning:
Touch and hold the [X] or [x] key for more
than 1 second to tune in a station.
Step tuning:
Touch the [X] or [x] key to manually tune in
a station.
Note:
• Manual tuning is cancelled if you do not operate
the unit for 7 seconds.
Recalling a preset station
A total of 12 TV stations can be stored (6-TV1
and 6-TV2).
There are 2 ways available to recall the preset
station.
● Using the [R] or [F] button
1. Press the [BAND] button or touch the [Band]
key to select the desired TV band. (TV1 or
TV2)
2. Press the [R] or [F] button to recall a
stored TV station.
● Using the Preset List screen
1. Touch the screen to display the menu, then
touch the [List] key.
2. Touch the corresponding Preset key to recall
the stored station.
* You can select the desired band by touching
the [Band] key.
* Touching and holding the desired Preset key
for more than 2 seconds will store the current
station into the preset memory.
3. Touch the [List] key again to return to the
previous screen.
WARNING
For your safety, the driver should not watch
the TV or operate the controls while driving.
Please note that watching and operating
the TV while driving are prohibited by law in
some countries.
