GRAPHITE 58G490 [22/192] Operation settings

Ɣ Slide the other guide bar onto protruding part of the connecting rod.

Ɣ Slide the guide bars together.

Ɣ Turn the guide bars over and align the connecting rod (25) when necessary, next tighten the pressing

screws (26) (g. I).

Fixing clamp (24) can be used to attach guide bars to processed material (g. G).

Ɣ Slide the ﬁxing clamp (24) into the ﬁxing groove (19).

Ɣ Set the bar position on the processed material and position of the ﬁxing clamp.

Ɣ Tighten the ﬁxing clamp (24) to avoid moving of the guide bar.

Ɣ For stable position of the guide bar, ﬁx it with two ﬁxing clamps (24) on two opposite sides of the bar

and processed material.

To guide the mini circular saw along the guide bar (18) (g. E) slide the saw base edge (9) into the guiding

groove (20) (g. F) in the guide bar. There are two ways to do this:

Ɣ Slide the mini circular saw from the end of the guide bar.

Ɣ You can also slide the mini circular saw from the side into the guide bar. To do so, tilt the mini circular saw

to the right and then press it on the guide bar.

OPERATION / SETTINGS

Check condition of cutting blade before use of the power tool. Do not use blades and discs with

dents, cracks or other damages. Immediately replace blade or disc that is worn out or damaged.

SWITCHING ON / SWITCHING OFF

Power indicator (3) is located in the back and upper part of the power tool casing, its illumination means

that the power tool is connected to mains power supply.

Hold the power tool with one hand when starting up and during operation. Keep your other hand in

safe distance from the tool. The power tool is equipped with the switch that protects against accidental

starting.

Ɣ Move the lever switch (1) to the front.

Ɣ Press the switch button (2).

Ɣ Release pressure on the switch button (2) to stop the power tool.

Wait a while after starting the power tool until the cutting blade or disc reaches its top speed, only

then you can proceed with your work. When working, do not use the switch of the power tool to

switch it on or o. You can operate the switch only when the cutting blade or disc has no contact with

processed material.

CUTTING DEPTH ADJUSTMENT

Cutting depth gauge (5) indicates cutting depth on the cutting depth scale (6).

Ɣ Loosen the clamp of the cutting depth gauge (5).

Ɣ Set cutting depth on the scale (6).

Ɣ Tighten the clamp of the cutting depth gauge (5).

To obtain the best possible cut quality, allow the cutting blade to plunge approx. 3 mm below bottom

surface of the material. When setting cutting depth for material of known thickness, add 3 mm correction.

In addition to setting value on the scale, it is always recommended to make a test cut or check how the

blade goes into the material without switching on the power tool.

CUTTING

Cutting line is deﬁned by cutting line indicators (11) and (12) (g. A).

Before making a cut, put the front part of the saw base (9) at against the material.
