GRAPHITE 59G261 [15/104] Operation settings

GRAPHITE 600Вт, диск 225 мм, сумка 59G261 [15/104] Operation settings

PREPARATION FOR OPERATION

INSTALLATION OF SANDING PAPER

The sander is equipped with working pad with hook-and-loop attachment, allowing quick and easy

replacement of sanding paper.

Ɣ Install sanding paper to working pad (8) so its holes match with holes in the working pad of the sander,

then press to ensure eﬃcient dust extraction.

Ɣ To remove sanding paper, lift edge of it on one side and pull (g. A).

Use perforated sanding paper, so the dust can reach dust extraction system through holes in the

working pad. With each replacement of sanding paper clean the working pad, remove dust and all

dirt with e.g. brush.

EXTENDING THE ARM

Long reach sander can be used with short arm to sand walls and with arm extension, which improves range

for sanding e.g. ceilings.

Ɣ Loosen locking cap (5) of the extension (2).

Ɣ Place extension arm (10) in the arm pipe (2), slide the reducer sleeve (11) into ﬁxing of the clamp cap (5),

set desired length and tighten the clamp cap (5) (g. b).

DUST EXTRACTION

Install suction hose (12) to the arm tip (2) or extension arm (10).

Ɣ Loosen the clamp cap (5), slide suction hose end (12) into the hole and secure by tightening the clamp

cap (5) (g. C, D).

Ɣ Connect the other end of suction hose to a suction system, e.g. workshop vacuum cleaner (the cleaner

must be designed for gypsum dust extraction).

When starting the work, ﬁrst switch vacuum cleaner, next the sander. When the work is ﬁnished proceed

inversely – switch oﬀ the sander ﬁrst, then the vacuum cleaner. This procedure allows to avoid unnecessary

dustiness in the workplace. Some types of industrial or workshop vacuum cleaners are equipped with

power supply socket for power tools and switching the vacuum cleaner on and oﬀ is automated, controlled

with switching the power tool.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the rating plate of the sander.

Switching on – change over the switch button (4) to position I (g. E).

Switching o – change over the switch button (4) to position O.

ROTATIONAL SPEED CONTROL

Wheel for speed control (3) is located on the sander body. Select the speed depending on your needs

(depending on the sanding paper used, hardness of processed material, type of work etc.). Rotating the

wheel for rotational speed control (3) increases or reduces speed of working pad (g. F).

SANDER OPERATION

Processed surfaces must be dry and must not contain foreign objects, e.g. screws, nails, bolts etc.

hold the sand rmly with both hands.

Ɣ Switch the sander on and wait until working pad reaches its full rotational speed.

Ɣ Put whole surface of the working pad to processed surface (articulated connection of working pad and

its cover will adjust to the surface automatically) (g. G).

Ɣ Apply moderate pressure and move the sander along processed surface with rotary movements, or

crosswise and lengthwise alternately.

Ɣ Overpressure will not increase sanding eﬃciency, but may cause faster wear of sander parts and sanding

paper.
