Chicago Pneumatic CP6135-D80L [2/36] Fig 01
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

Chicago Pneumatic CP6135-D80L [2/36] Fig 01

Chicago Pneumatic CP6135-D80L [2/36] Fig 01
Fig. 01
Fig. 02
Air diagram
Model
Drive
Torque
Bolt
capacity
Speed Weight
Inner Hose
Dia.
Dimensions
L x H x W
Air
consumption
Air Inlet
Sound-
Pressure
L
pA
Sound-
Power
L
wA
Vibrations
Working Max Max
At load
ahd k
L
W
H
1 2 3 4 5 6
7
8 9 10 11 12
[inch]
[ft.lbs]
[Nm]
[ft.lbs]
[Nm]
[inch.]
[mm]
[min-1]
[lb]
[kg]
[inch.]
[mm]
[inch.]
[mm]
[SCFM]
[Nl/s]
[inch] [dB(A)] [dB(A)] [m/s²] [m/s²]
CP6135-D80 1-1/2”
740 - 4,055
1,000 - 5,500
5,900
8,000
1-7/8"
M48
2,900
35.3
16
5/8”
16
16.1" x 7.8" x 5.3"
409 x 198 x 135
84.5
40
NPT 1/2"
Female
99 110 10.9 6.3
CP6135-D80L spline #5
740 - 4,055
1,000 - 5,500
5,900
8,000
1-7/8"
M48
2,900
35.3
16
5/8”
16
16.1" x 7.8" x 5.3"
409 x 198 x 135
84.5
40
NPT 1/2"
Female
99 110 10.9 6.3
L
H
B
A
5/8”(16mm)
5/8”(16mm)
1”(25mm)
5/8”(16mm)
5/8”(16mm)
1”(25mm)
1”(25mm)
1”(25mm)
