To reduce risk of injury, everyone using, installing,

repairing, maintaining, changing accessories on, or

working near this tool must read and understand

these instructions before performing any such task.

The goal of Chicago Pneumatic is to produce tools that help you work safely and

efficiently. The most important safety device for this or any tool is YOU. Your

care and good judgment are the best protection against injury. All possible

hazards cannot be covered here, but we have tried to highlight some of the

important ones.

Air Supply Requirements

Lubrication

Operation

Sound pressure level 95 dB(A) in accordance with Pneurop PN8NTC1.2. For sound

power, add 10 dB(A).

Maintenance

1. Supply tool with 90 psig (6.2 bar) of clean, dry air. Higher pressure drastically

reduces tool life.

2. Connect tool to air line using pipe, hose, and fitting sizes shown on page 12.

1. Use an air line lubricator with SAE #10 oil, adjusted to two (2) drops per minute. If an

air line lubricator cannot be used, add air motor oil to the inlet once a day.

2. Check clutch grease once each month.

This impact wrench is equipped with a regulator to enable adjustment of output

power. Turn the regulator knob counter-clockwise for maximum power, clockwise to

reduce power.

Noise & Vibration Declaration*

Vibration value 4.3 m/s , re. ISO 8662-7.

1. Disassemble and inspect air motor and impacting clutch every three (3) months if the

tool is used every day. Replace damaged or worn parts.

2. High wear parts are underlined in the parts list.

3. To keep downtime to a minimum, the following service kits are recommended:

C157304 Tune-Up Kit, C157305 Repair Kit

*These declared values were obtained by laboratory type testing in compliance with the stated standards and are not

adequate for use in risk assessments. Values measured in individual work places may be higher than the declared

values. The actual exposure values and risk of harm experienced by an individual user are unique and depend upon the

way the user works, the workpiece and the workstation design, as well as upon the exposure time and the physical

condition of the user. We, Chicago Pneumatic, cannot be held liable for the consequences of using the declared values,

instead of values reflecting the actual exposure, in an individual risk assessment in a work place situation over which we

have no control.

We, Chicago Pneumatic Tool Company, 1800 Overview Drive, Rock Hill, SC 29730 USA, declare under

our sole responsibility that the product to which this declaration relates, is in conformity with the

requirements of the Council Directive of June 1989 on the approximation of the laws of the Member

States relating to machinery (89/392/EEC).

Machine Name CP-6300-RSR Impact Wrench

Machine Type Assembly Power Tool for Threaded Fasteners - No other use is permitted.

Serial No. Tools with No. 99134A or higher

Technical Data

3/8" Sq. Dr.

Air pressure 90 psig (6.2 bar)

Torque range 36 -153 ft.- lb. (49 -207 Nm)

Ult. torque @ 90 psig (6.2 bar) 180 ft.-lb. (244 Nm)

Harmonized Standards Applied TC255

National Standards Applied ISO 8662-7, Pneurop PN8NTC1.2

Name And Position Of Issuer W.A. LeNeveu, Vice President, Chicago Pneumatic Tool

Company.

Signature of Issuer

Place and Date of Issue Rock Hill, SC 29730 USA, May, 1999

Free speed 6800 RPM

Air consumption 12 cfm (5.7 l/s)

Model "A"

C157303 Rev. D

CP-6300-RSR

Impact Wrench

Limited Warranty: The "Products" of the Chicago Pneumatic Tool Company ("CP") are warranted to be

free from defects in material and workmanship for one year from the date of purchase. This Warranty

applies only to Products purchased new from CP or its authorized dealers. Of course, this Warranty does

not apply to products which have been abused, misused, modified, or repaired by someone other than CP

or its Authorized Service Representatives. If a CP Product proves defective in material or workmanship

within one year after purchase, return it to any CP Factory Service Center or Authorized Service Center for

CP tools, transportation prepaid, enclosing your name and address, adequate proof of date of purchase,

and a short description of the defect. CP will, at its option, repair or replace defective Products free of

charge. Repairs or replacements are warranted as described above for the remainder of the original

warranty period. CP's sole liability and your exclusive remedy under this Warranty is limited to repair or

replacement of the defective Product. (There Are No Other Warranties Expressed Or Implied And CP

Shall Not Be Liable For Incidental, Consequential, Or Special Damages, Or Any Other Damages,

Costs Or Expenses Excepting Only The Cost Or Expense Of Repair Or Replacement As Described

Above.)

adapters absorb impact power and could break. Use deep sockets wherever

possible.

! Never operate the tool off of the work. It may run too fast and cause the accessory

to be thrown off the tool.

! Serious injury can result from over-torqued or under-torqued fasteners, which

can break, or loosen and separate. Released assemblies can become

projectiles. Assemblies requiring a specific torque must be checked using a

torque meter.

Note: So-called "click" torque wrenches do not check for potentially dangerous

over-torque conditions.

Workplace Hazards

! Slip/Trip/Fall is a major cause of serious injury or death. Beware of excess hose

left on the walking or work surface.

! High sound levels can cause permanent hearing loss. Use hearing protection as

recommended by your employer or OSHA regulation (see 29 CFR part 1910).

! Maintain a balanced body position and secure footing.

! Be in control of the throttle at all times. Do not get caught between the tool and the

work.

! Repetitive work motions, awkward positions and exposure to vibration can be

harmful to hands and arms. If numbness, tingling, pain or whitening of the skin

occurs, stop using the tool and consult a physician.

! Avoid inhaling dust or handling debris from the work process which can be

harmful to your health. Use dust extraction and wear respiratory protective

equipment when working with materials which produce airborne particles.

! Proceed with care in unfamiliar surroundings. Be aware of potential hazards

created by your work activity. This tool is not insulated for coming into contact with

electric power sources.

! Some dust created by power sanding, sawing, grinding, drilling and other

construction activities contains chemicals known to the State of California to

cause cancer and birth defects or other reproductive harm. Some examples of

these chemicals are:

- Lead from lead based paints

- Crystalline silica bricks and cement and other masonry products

- And Arsenic and chromium from chemically-treated rubber

Your risk from these exposures varies, depending on how often you do this type

of work. To reduce your exposure to these chemicals: work in a well ventilated

area, and work with approved safety equipment, such as dust masks that are

specially designed to filter out microscopic particles.

Additional Safety Topics

! This tool and its accessories must not be modified.

! This tool is not recommended for use in explosive atmospheres.

! Operators and maintenance personnel must be physically able to handle the bulk,

weight and power of the tool.

! For tools using the pin and O-ring socket retention system, use the O-ring to

securely retain the socket pin.

For Additional Safety Information Consult:

! Your employer union and/or trade association.

! US Department of Labor (OSHA); www.osha.gov; Council of the European

Communitieseurope.osha.eu.int.

! “Safety Code For Portable Air Tools” (B186.1) available from: www.ansi.com

! “Safety Requirement For Hand-Held Non-Electric Power Tools” available from:

European Committee for Standardization, www.cenorm.be

Air Supply And Connection Hazards

! Air under pressure can cause severe injury.

! Always shut off air supply, drain hose of air pressure and disconnect tool from air

supply when not in use, before changing accessories or when making repairs.

! Never direct air at yourself or anyone else.

! Whipping hoses can cause serious injury. Always check for damaged or loose

hoses and fittings.

! Do not use quick disconnect couplings at tool. See instructions for correct set-up.

! Whenever universal twist couplings are used, lock pins must be installed.

! Do not exceed maximum air pressure of 90 psi (6.2 bar) or as stated on tool

nameplate.

Entanglement Hazards

! Keep away from rotating drive.

! Do not wear jewelry or loose clothing.

! Choking can occur if neckwear is not kept away from tool and accessories.

! Scalping can occur if hair is not kept away from tool and accessories.

! Avoid direct contact with accessories during and after use. Gloves will reduce the

risk of cuts or burns.

! Use only proper accessory retainers (see parts list). Use deep sockets wherever

possible.

Projectile Hazards

! Always wear impact-resistant eye and face protection when involved with or near

the operation, repair or maintenance of the tool or changing accessories on the

tool.

! Be sure all others in the area are wearing impact-resistant eye and face

protection.

! Even small projectiles can injure eyes and cause blindness.

! Do not use hand sockets. Use only impact wrench sockets in good condition.

! Sockets in poor condition or hand sockets used with impact wrenches can

shatter.

! Always use the simplest hook-up possible. Long, springy extension bars and
