6 TTX7503z
English
4. SPECIFICATIONS
Reception channels: VHF CCIR 2 to 12 ch[CCIR “L” L5 to L12 ch (when receiving country has been
set to France.) ]
UHF CCIR 21 to 69 ch
Antenna input: 75 Ω unbalanced
voltage: 14.4 V
Grounding: Negative terminal grounding
Power consumption: 0.8 A or less
External dimensions: 178 mm (Width) ✕ 25 mm (Height) ✕ 160 mm (Depth)
Weight: 0.7 kg
* The specifications and design may be subject to change without prior notice due to improvements.
178mm
6.4mm
160mm
25mm
